Strawberry Cleaner Automatic Strawberry Washing Machine

Wuxi Xinrun Protective Film Co., Ltd. / 2022-07-05

Strawberry Cleaner Automatic Strawberry Washing Machine

  • After-sales Service:Door to Door or Video
  • Warranty:1 Year
  • Voltage:380V
  • Power:5.6kw
  • Customized:Customized
  • Material:304 Stainless Steel or According to Customer Requi

=== Base Info ===

  • Model NO.:TSXQ-50
  • Effective Dimensions:3500*720*100 mm
  • Transport Package:According to Customer Requirement
  • Specification:5200*1650*1900 mm
  • Trademark:Ambitious
  • Origin:China
  • HS Code:8438600000
  • Production Capacity:20pieces,Year

=== Description ===

Basic Info.

Model NO. TSXQ-50 Effective Dimensions 3500*720*100 mm Transport Package According to Customer Requirement Specification 5200*1650*1900 mm Trademark Ambitious Origin China HS Code 8438600000 Production Capacity 20pieces/Year

Product Description

1.Bubble Washing and Cleaning Machine:
The cleaning machine is composed of tank, conveying, bubble wave, high-pressure spraying, filtering, and lifting structure, which is widely used for cleaning and removing impurities such as vegetables, fruits, meat, aquatic products, and medicinal materials.

The main machine is made of high-quality stainless steel. The bubble wave and high-pressure spray use the principle of water impact to make the material roll up and down, left and right, and continuously discharge the material. The sediment and impurities in the material are cleaned. The outlet is equipped with a secondary spray cleaning. The device is equipped with a floating water overflow port on the side of the cleaning tank, and the sediment can be discharged from the sewage outlet to achieve a cleaning effect

Strawberry Cleaner Automatic Strawberry Washing Machine
2.Application of the Washing Machine
The Washing Machin Vegetable Washer is widely used in the cleaning of leafy vegetables, berries vegetables, pickled vegetables, fruits, aquatic food etc.
Strawberry Cleaner Automatic Strawberry Washing MachineStrawberry Cleaner Automatic Strawberry Washing Machine

Strawberry Cleaner Automatic Strawberry Washing Machine
Through the explosion of air and water flow to separate the foreign matter and vegetables. The foreign matter (sand, nails, wire) which has greater density than water will be precipitated at the bottom of the tank and discharged through the sewage outfall. The floating which density less than water (leaves, Impurities, hay, etc.) was filtered and separated by the filter. Finally, Vegetable will be sent out by the conveyor belt after spayed by clean water to complete the cleaning.
Strawberry Cleaner Automatic Strawberry Washing Machine
3.Technical Parameters of the washing machine:
The washer consists of conveying system (mesh belt, motor and tank), Hoist system,  frame and spray pipe, air pump etc.
Model5.6kw
Voltage380v/50HZ
Dimensions5200*1650*1900 mm
Effective size3500x720x100mm
Water capacity1500L
Strawberry Cleaner Automatic Strawberry Washing Machine
4.Bubble washing machine for vegetable or fruit processing line:
The continuous bubble washing machine not only can be used individual, but also equipped in vegetable production line.
Strawberry Cleaner Automatic Strawberry Washing Machine
Strawberry Cleaner Automatic Strawberry Washing Machine
5.-Packing and shipment
Strawberry Cleaner Automatic Strawberry Washing Machine

6.-Company&Workshop:

Zhucheng Tianshun Machinery Co.,Ltd, extablished in 2008, manufacturer of full set food processing machineries in frying equipment, washing cleaning equipment, cooking and blanching equipment, cutting equipment, pasteurization, air-dry equipment, drying equipment, package equipment etc
It is widely used in fried food, conditioning food, surimi products, vegetables, fruits, aquatic products, canned food, meat, soy products, snack food, central kitchen planning and herbal processing and other fields.

Strawberry Cleaner Automatic Strawberry Washing Machine
