CO2 RF Laser Marking Machine Laser Engraving Machine for Plastic Shoes

• Laser Visibility：Visible
• Applicable Material：Nonmetal
• Cooling System：Air Cooling
• Technical Class：Continuous Wave Laser
• Laser Wavelength：10640nm
• Laser Classification：IV

=== Base Info ===

• Model NO.：MT-RF30
• Type：CO2 Laser
• Marking Method：Laser Marking
• Wavelength：10600nm
• Transport Package：Standard Wooden Box
• Origin：Guangdong, China
• Production Capacity：200

=== Description ===

10x10/16x16/22x22/30x30(Optional)

Laser Generator

USA Imported RF Metal Laser Tube

Laser Power

10W-60W (Optional)

Wavelength

10640nm

Min Character

0.4mm

Marking Speed

≤7000mm/s

Marking Depth

≤0.3mm

Repeat Precision

±0.003mm

Cooling Style

Air Cooling

Power Supply

220V(±10%)/50Hz/15A

Gross Power

<1.5KW

Operating Temperature

10ºC-45ºC

Warranty

12 Months

Dimension (cm)

120x33x122 (Optic System)

56 x84 x83 (Control System)

Weight (kg)

350



Feature:

1) CO2 Laser Marking Machine adopted back focalization; laser power is controlled by the software and serially adjustable. It is applicable to fine marking on nonmetal materials with low requirements.

2) Adopting imported Co2 RF laser tube which has excellent performance and long life<20k hours>.

3) Adopting imported American high-speed galvanometer system with high speed, high precision and stable performance.

4) Adopting imported optics lens, low loss, excellent focalization performance.

5) The marking software is mightiness, under WINDOWS interface, compatible with CORELDRAW, AUTOCAD, PHOTOSHOP etc. a variety of software output files. Support PLT, AI, DXF, BMP and other documents, directly using SHX, TTF font. Support automated coding, serial number, batch number, date, bar code and two-dimensional code marking.



Applicable Materials:

Mactron CO2 Laser Engraving Machine is suitable for nonmetal materials such as leather, cloth, wood, bamboo, paper, organic materials, plastic, epoxy resin etc.



Applicable Industry:

This Series CO2 Laser Engraving Machine is suitable for electronic components, medicines, food, drinking package, leather products, rag trade, woodworks, craftworks and package.





Sample




Company Information

Production Flow



Our Services







FAQ

1) What are the primary products of your company?

Our primary products include laser engraving machine, laser cutting machine, laser marking machine and laser welding machine.



2) Where is your laser equipment applied to?

Our laser marking machine is applied to textiles, leather, shoes, advertisement, gifts, electronic components, stamp, etc.

10W Fiber Laser Marking Machine is suitable for all kind of metal, industrial plastic, electroplates, metal-coated materials, rubbers, ceramics and so on.



3) What are the advantages of your laser equipment?

Our laser equipment has several advantages.

------Firstly, high quality and precision are the featured properties of our laser marking machine. Our laser marking machine employs the domestic leading "Smart Engraving" technology, which could clearly engrave 2mm characters and 1mm letters on the materials.

------Secondly, compare with the laserpro, universal, trotec, the performance of Mactron laser machine. What's more, our performance price ratio is the best.



4) How to do control the quality when you produce laser equipment?

We introduce international advanced production technology, and strictly implement a series of measures of quality and cost control to ensure the quality of laser marking machine. In addition, all raw materials are strictly inspected in accordance with international standards before they are put into production.



5) Which countries are your laser machinery sold to?

Our laser marking machine sell all over the world, such as Australia, Singapore, Saudi Arabia, Turkey, India, Italy, and other countries.



6) How long is the delivery time?

The laser marking machine will be delivered to you within 1-2 weeks after the order is confirmed.



7) What certificate has your company got?

All of our laser marking machine with CE, ISO, SGS



8) How to choose a good quality Fiber laser marking machine?

1) High quality, if you want to choose a cheap laser marking machine. Maybe the quality is too bad. And you must buy the other one after you use it for a period of the time. This situation will effect your production. So the quality of the machine is so important than others.

2) Good After-sales service, which is very important. Good after-sales service representative the image of the company .After you use the laser marking machine and find some problem of machine in some respect. The good after-sales can dealing with it effectively and protect the rights of consumers.

3) Strong technical support. Because of time difference, when you need help, other place maybe is sleeping. So the effectively contact information and serve is also useful to you.

Package and Shipping



Certification
