Donghang Plastic Forming Machine

=== Base Info ===

=== Description ===

Basic Info.

Model NO. DHBGJ-480L Ruian China Good Price Factory Supply Transport Package Wooden Packaging Specification CE Trademark Donghang Origin China HS Code 8477409000

Product Description

Products Description:
It's a new type one that combines hydraulic and servo working  of main forming machine and also brings to more improvement and innovation.With easy operation, calm running, conveninent maintenance and stable function.It can provide PVS,PS,PET etc.All kinds of covers.


Functions and Features
1) Mold adopts clamping plate, easy to adjust and install.
2) Main motor adopts servo governor: Cutting frequency is adjustable of 10~28 Time/min. Moderate the suitable cutting frequency on the basis of stoke length and difficulty of forming.
3) Servo feeding corporate with squeeze motion. Smooth running, process synchronized, the maximum line control is 240mm, it means the dimensions can designed differently in this range.
4) Forming heating plate automatically close and open. It can power on delay, limits the waste of materials in once time. The heating power and temperature can be lowed by adopted contact heating of the plate. Through which it saved energy and enhance the stability of plastic piece.

Technical Parameter:

Punching Frequency	20-35time/min
Max.Forming Depth	50mm
Max.Forming Area	260*340mm²
Air-compressor	Less than 0.2m³/min
Pressure	0.4-0.7MPa
Power	20Kw
Overall Dimension	4200*750*1700mm
Weight	1500Kg

If you are interested in our machine, please feel free and contact me.
Ruian Donghang Packing Machine Co.,Ltd
Add: Nantuozhan Industrial Zone Feiyun Town,
Ruian Zhejiang PR.China Post code:325207
Contacter: May Zheng


Web:http://cndonghang.en.made-in-china.com
