Fruit Powder Spray Powder Tower / Spray Drying Tower/Frozen Drying Tower

• After-sales Service：Timely After Sale Service
• Warranty：24month
• Type：Manufacture
• Voltage：380V
• Power：Manufacture
• Customized：Customized

=== Base Info ===

• Model NO.：JPM-NJ-TPL
• Transport Package：Accroding to Your Requirements
• Specification：belle
• Trademark：JUMP
• Origin：China
• HS Code：8548900090
• Production Capacity：1000

=== Description ===

Basic Info.

Model NO. JPM-NJ-TPL Transport Package Accroding to Your Requirements Specification belle Trademark JUMP Origin China HS Code 8548900090 Production Capacity 1000

Product Description

Complete lemon Juice Production Line

Products Introduction
This RCGF Wash-filling-capping 3-in-1unit: Beverage Machinery is used to produce jucie for hot filling. Beverage Machinery can finish all the process such as washing bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.
(1) Complete juice production line includes: Washing-filling-capping 3 in 1 machine, lamp inspection, label shrinking machine, inkjet printer, hot shrink film packer and conveyors. It is a full automatic production line.
(2) RCGF juice hot filling machine is  used in the beverage filling operations. The three functions of bottle wash, fill and seal are composed in one body of the machine. The whole process is automatic.
(3) RCGF Filling Machine is used in filling juices, mineral water and purified water in bottles made of polyester and plastics. The machine can also be used in hot filling if being installed with temperature controlling device. The handle of the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles.
(4)The filling operation is faster and more stable because the micro pressure filling operation of the new type is adopted. There the output and benefit of the machine is higher than the machinery of the same specifications.
(5)The advanced Siemens programmed controller (PLC) is adopted to control the machine to run automatically while a transducer is used in the bottle -entering chains to adjust speeds and coordinated with the transducer of the main machine to make the operations of moving bottle forward steadily and reliably.
(6)It is convenient to operate with higher automation because every part of the machine is inspected to run with photo electricity, On the bases, the filling parts of the machine can be changed into filling methods of lower vacuum.
(7)The filling category of lower vacuum (Z type machine) is applicable in glass bottles, filling alcohol, soy and such like materials. The aluminum theft proof cap and plastic cap can be adopted. The machine is an idea-preferred equipment for beverage maker.
Characteristics
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
Flow chart:
A)Bottle production line  PET Resin --Injection moulding machine -Botlte blowing machine --PET bottle
B)Water treatment system Raw water--Pump--Silica sand filter--Carbon filter--Water softner--Reverse Osmosis -UV sterilizer-Ozone generator--Finished water tank
C)Filling&Packing part   Bottle unscrambler--Air conveyor--Washing,filling,capping 3in1 machine--Light checker--Blow dryer--Dater printer--Lableing machine --Packing machine -Stock

Technical Parameter:

Model	Washing heads	Filling heads	Capping heads	Capacity(b/h) On 500ml	Motor power (KW)	Overall dimension (mm)
RCFG 14-12-4	14	12	4	2000-4000	3.7KW	2500x1850x2400
RCFG 18-18-6	18	18	6	5000-7000	4.4KW	2800x2000x2400
RCFG 24-24-8	24	24	8	8000-12000	5.3KW	3100x2100x2400
RCFG 32-32-10	32	32	10	12000-15000	6.5KW	3500x2100x2400
RCFG 40-40-10	40	40	10	16000-20000	7.5KW	3600x2200x2400
RCFG 48-48-12	48	48	12	20000-24000	9.5KW	4200x2300x2400
RCFG 60-60-15	60	60	15	25000-30000	12KW	4800x2300x2400
