Cdc-F15L Series Multichannel Reversing Valve

• Function：Balance, Pressure Regulating, Reversing, Flow Control
• Installation：Threaded Cartridge
• Drive：Hydraulic
• Type：Pilot-Operated Type
• Warranty：One Year
• Original：Yes

=== Base Info ===

• Model NO.：CDC-F15L
• Application：General
• Material：Casting
• Pressure：Medium Pressure
• Structure：Control
• Standard or Nonstandard：Standard
• Selling Units：Single Item
• Temperature of Media：Normal Temperature
• Name：Stacked Pressure Reducing Valve
• Transport Package：Box and Carton Package
• Specification：hydraulic
• Trademark：XLF
• Origin：China
• HS Code：8481201000
• Production Capacity：3000sets,Month

=== Description ===

Basic Info.

Model NO. CDC-F15L Application General Material Casting Pressure Medium Pressure Structure Control Standard or Nonstandard Standard Selling Units Single Item Temperature of Media Normal Temperature Name Stacked Pressure Reducing Valve Transport Package Box and Carton Package Specification hydraulic Trademark XLF Origin China HS Code 8481201000 Production Capacity 3000sets/Month

Product Description

Product Advantage
As the forklift is becoming more and more widely application, the user of the security requirement of increasing the forklift operation, forklift truck on the original configuration of multi-way valve can not fully meet the requirements, especially out
Mouth fork has increased a lot of security force, the CDC * - F15L series of multi-way valve is developed for the realization of the functional requirements.
The CDC * - F15L series of multi-way valve in addition to meet the forklift, tilt, belong to control and turned to the functional requirement of the oil supply, also increases the speed control forklift truck door frame drop
Built-in limit valve, fall protection of electromagnetic valve and emergency manual switch valve as well as the system unloading electromagnetic valve, etc. The valve can be realized the operator to leave after a forklift forklift seat door frame automatically
Nurse, can completely avoid potential safety hazard due to wrong operation.
CDC * - F15L series of multi-way valve nominal pressure and nominal flow compared with sizing multi-way valve, the valve has advanced performance, therefore, the function is all ready, compact structure, and work
Reliable, high security features, which can realize forklift truck hydraulic system upgrade.
U system unloading electromagnetic valve: the solenoid valve can be realized when the operator leave the forklift seat, hydraulic system, automatic cut off the multi-way valve all loading and unloading actions will be stopped
U fall protection solenoid valve: only after open the solenoid valve, control in operation
Taken the emergency hand switch valve: under the case of electricity or electromagnetic valve, set up emergency manual switch valve
Taken the built-in steady flow valve: feed components with steady flow valve body, the steering system of steady flow
Taken the built-in limit valve: compound directional body drop speed limit valve, control forklift truck door frame rate of descent
Taken the built-in one-way valve: every league reverse body has a built-in check valve, preventing the oil flow back
U set stem self-locking: prevent the forklift truck door frame due to internal pressure may cause the vibration of the cylinder, and when the engine flameout tilt lock cylinder, avoid misoperation made before the fork truck door frame
After tilt, cause potential safety hazard
U set up double valve: the main relief valve pressure control system, guarantee the normal work of the steering system pressure relief valve
Taken the additional valve, reversing the ends of the body, according to need to add the overload valve or valve
Taken the body structure: chip structure, 1 ~ 10 league in any combination
Taken the stem the median function: A, O, Y, Z, etc


Model Coding


Unit code

Design code
Pressure grade   F: 20MPa
Nominal size   15mm
Joining port   L:  Screw
Spool returning   T:  Spring   W:  Ball
Block No.1 spool function
Block No.2 spool function
Dividing flow (L/min)

Technical Specification
