Type Ytr180b Rotary Drilling Rig

=== Base Info ===

=== Description ===

Basic Info.

Model NO. YTR180B Type Crawler Max. Drilling Depth(M) 65 Max. Drilling Diameter(mm) 1500 Output Torque (Kn.M) 180 Goss Weight (Including Standard Drilling 56.5 Weight Under Transport State(T) 47.2 Traction Force(Kn) 370 Collocating Power(Kw) 246 Rotating Speed of Power Unit (Rpm) 125/133 Max.Boosted Pressure (Kn) 150 Max. Lifting Force (Kn) 160 Noise Without Noise Transport Package Standard Packing Specification ISO9001 Trademark Glorytek Origin Beijing China Production Capacity 100 Sets Per Month

Product Description

Name: YTR180B Rotary Drilling Rig

Key words: Rotary drilling rig; Rotary drill rig; Piling drilling rig; Piling machine; Drill rig

Description of YTR180B Rotary Drilling Rig:

Our rotary drilling rig absorbs the advantages of domestic and foreign famous brand products in design and techniques whose major performance parameter has reached international level of the similar product and whose components all adopts international famous brand products to guarantee the reliability of complete machine. It can be matched with drilling tools such as short spiral bit, common drilling bucket, and bailing drilling bucket etc. And can be drilled into clay layer, gravel bed, pebble bed and weathered mudstone bed. It has advantages such as high working performance, strong site adaptability, and obvious environmental protection effect., and is widely used in the pile foundation construction of railway and roadway bridges, urban traffic construction, and high-rise buildings etc, and also is the high efficiency drilling equipment for large and medium pile foundation engineering construction.

Product model parameter	YTR280	YTR260B	YTR220	YTR180B
Max. drilling depth(m)	90	80	68	65
Max. drilling diameter(mm)	2200	2000	2000	1500
Output torque (kN.m)	280	260	220	180
Rotating speed of power unit (rpm)	6.5-29	41118	41113	7-32
Max.boosted pressure (kN)	215	190	190	150
Max. lifting force (kN)	230	230	196	160
Left/right tilting angle of mast(°)	3.5	3.5	3.5	3.5
Forwarding tilting angle of mast(°)	3.5	3	3	3
Engine manufacturer and model	C9ACERT EFI(Optional 1: Doosan; Optional 2: Commins)	Commins QSM11-C330	Commins6C8.3/ 6CTA8.3 (Optional: Caterpillar)	Commins 6BTA5.9-C169/B5.9C
Collocating power(kw)	260	246	186/194	125/133
Lifting force of main winch (kN)	270	240	240	170
Diameter of steel rope of main winch(mm)	32	28	28	26
Max. lifting speed of main winch(m/min)	80	77	70	65
lifting force of auxiliary winch (kN)	120	120	120	50
Diameter of steel rope of auxiliary winch(mm)	20	20	20	16
Max. lifting speed of auxiliary winch(m/min)	70	70	70	56
Chassis model	CAT 336D (Optional1: Doosan; Optional2: Bonny)	Bonny	Bonny (Optional: Caterpillar)	Bonny
Traction force(kN)	270	410	390	370
Goss weight (including standard drilling tool)(t)	80	78	73	56.5
Weight under transport state(t)	68	67	63	47.2
