Agricultural Big PE Film Blowing Machine

=== Base Info ===

=== Description ===
LDPE/LLDPE/HDPE/MLLDPE/EVA/EAA etc.film width2100mm2500mm3000mm3700mm4200mmthickness0.01--0.16mmscrew diameterΦ105mm*1Φ120mm*1Φ135mm*1/Φ90mm*2Φ145mm*1/Φ95mm*2Φ155mm*1/Φ120mm*2L/D ratio30:1die diameterΦ550mmΦ650mmΦ750mmΦ800mmΦ1100mmdie structureSpiral mandrel die chrome plated surface 40Crmain power55kw75kw90kw*1 / 45kw*2130kw*1 / 55kw*2160kw*1 / 75kw*2max output260kg/h330kg/h380kg/h450kg/h650kg/hTorque motor winderoptional equipmentauto-loader device, film surface treater, air compressor, fast change net, double center rewinder/auto rewinder, flat cage roll winder, rotary die head, double wind air ring.

PICTURES FOR REFERENCE:






Certificates:
