2019 Newest Visual Positioning 20W Fiber Laser Marking Machine

• Laser Visibility：Invisible
• Applicable Material：Metal and Non Metal
• Cooling System：Air Cooling
• Technical Class：Pulse Laser
• Laser Wavelength：Fiber Laser
• Laser Classification：Solid Laser

=== Base Info ===

• Model NO.：LBGX-300-B
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Laser Source：Ipg, Raycus, Max
• Marking Depth：≤0.6mm(Depand on Power, Material, Ect.)
• Marking Speed：7000mm,S
• Marking Area：110*110mm, 175*175mm, 255*255mm, 300*300mm
• Transport Package：Wooden Case
• Specification：20w 30w 50w 70w 100w
• Trademark：Label Laser
• Origin：China
• HS Code：8456110090
• Production Capacity：300 Sets Per Month

=== Description ===

Basic Info.

Model NO. LBGX-300-B Type Optical Fiber Laser Marking Machine Marking Method Scanning Marking Laser Source Ipg, Raycus, Max Marking Depth ≤0.6mm(Depand on Power, Material, Ect.) Marking Speed 7000mm/S Marking Area 110*110mm, 175*175mm, 255*255mm, 300*300mm Transport Package Wooden Case Specification 20w 30w 50w 70w 100w Trademark Label Laser Origin China HS Code 8456110090 Production Capacity 300 Sets Per Month

Product Description

Automatic Camera Visual Positioning Laser Marking Machine For Pcb Marking

Product Features:

Visual Positioning Laser Marking Machine can be placed at any angel without fixing the products. Its economic with best quality, and it mainly used for marking on metal and nonmetal material, without consumable,with cost effective. It boasts fast marking speed and high marking precision.Work efficiency has been greatly improved. It's widely used and well accepted in prevailing international market.


For some small parts or small letters, the positioning is not easy to be done by hand, so a new CCD automatic identifying & positioning laser marking machine 3d for ultra small parts and letters marking was launched.

As the small parts and letters are hard to be positioned and marked by hand, this machine adopts a 5 megapixel coaxial CCD camera, can realize automatic identifying and positioning for marking. It will enlarge the marking area, identify the shape and marking area of the object in the software, and achieve 0.02mm ultra high positioning accuracy.

This laser marking machine 3d is especially suitable for marking on ultra high-precision and valuable parts which is not easy to be positioned by hand, such as: electronic components, IC chips, circuit boards, resistors, small capacitors, metal buttons, pens, etc., more suitable for marking on the parts which is not possible for positioning by hand.

Technical parameters

Laser Type	Fiber laser
Laser Power	20W 30W 50W 100W
Model	LBFX-600-I
Laser Wavelength	1064nm
Laser Source	IPG, Raycus, Max, or others based on customers' requirements
Marking Area	110*110mm,145mm*145mm, 150*150mm, 175mm*175mm, 255mm*255mm, 300mm*300mm
Marking Depth	≤0.6mm(depand on power, processed material and procedure)
Marking Speed	7000mm/s
Repeated Precision	±0.003mm
Marking Contents Type	Figure, letter, common and  special charaters, automatic calender, count, serial no., ect. Barcode: code39/code128/PDF417, ect. QR code: DataMatrix, QR, ect. Graphic: image, multi-language charaters, CAD, DXF, BMP, JPEG, PLT, ect. Fixed point, straight line, broken line, circle, ellipse, elliptical arc, Bezier curve, ect. can also custom as request.
Working Distance	180±2mm
Minimum Line Width	0.05mm
Minimum Character	0.2mm
Matching Line Speed	≤120m/min
Applicable Materials	Metal HDPE, Alloy material, Thin film material
Operation System and Software	Windows XP/2000 / Windows 7 LABELMARK
Communication Interface	RS-232 serial port, USB port, ect.
Cooling Mode	Air cooling
Temperature of Operation Environment	5ºC~35ºC
RelativeHumidityof  Operation Environment	<85%(frost is not allowed)
Power Input	220V ( ±10%)/ 50HZ( ±5%)   single phase
Power Consumption	<=500W
Communication Interface	USB


Marked Samples:




Applicable field and material:

Application materials
Gold & silver, stainless steel, ceramics, plastic, glass, stone, leather, cloth, bamboo and so on, auto accessories marking, tobacco products marking, beer bottle marking, ring marking, electronic products marking etc.

Application industry
fiber laser marking machine is applied in gold & silver jewelry, sanitary ware, food packing, tobacco products, medicine packing, medical apparatus and instruments, watches & glassware, auto accessories, electronic hardware industries.

Packing deail





Company Profile

Wuhan Label Laser Science & Technology Co.,Ltd. has been specialized in researching and manufacturing industrial laser marking equipments, laser welding machine, laser cleaning machine for customers since 2000.

With over 18 years development,Label Laser has accumulated rich technical and design experience for industrial marking system, a large number of successful cases and
well-know customers in industries of machinery, automotive, iron and steel, petroleum, petrochemical, aviation, electronic products, tools, instrument, apparatus, etc.







Why choose us


A. More than 18 years laser marking, welding, cleaning, processing, manufacturing, research and design rich experience.

B. Professional technical group for customized industrial laser marking system.

C. More than 3000+marking solution cases accumulated in domestic and oversea markets.

D. 100% strict QC for both raw materials and finished products.

E. Utility Model Patent Certificates,involved 3M Flexible label paper marking,Nameplate Auto marking ,Engine cylinder block and head pass-type auto marking,Automobile forged wheel hubs pass-type auto marking, copyright of computer software,etc.

F. ISO,CE,SGS certified and complete aftersales service team.


FAQ


Q1: What type of the machine suitable for us?

Please tell us what material will be marked/engraved and the depth of marking/engraving, we will advise you the suitable model machines. If you can provide material picture, it is better. It is best if you send sample to us, we will mark on it. Sample with marking pictures and videos will be sent to you for checking. Or we can send the sample to you for quality and marking effect checking.

Q2: If we do not know how to use the machine,can you teach us?

Yes, we will. Our user manuals are together with goods shipment. We can also send operation video to you for study.

If you come to our factory in China, our technicians will offer you free training until you can use machine freely.

Our professional engineer can come to your country for trainning, installation, adjusting, ect.

Q3: How about the delivery time?

For standard machine, lead time is 10-15 days.

Q4: How about the warranty time?

Our fiber laser machine warranty time is 12 months. Please send back the broken parts to us, we will send the new and replaced one to you. We suggest you take one extra set of spare parts together with your order which will be more convinient for your production line continurous running.
