Model | HT-TTQ100 Double row full automatic donut machine | HT-TTQ100A Double row automatic electrical and gas integrated donut machine | HT-TTQ100B Double row automatic gas type donut machine |
Voltage | 220V(can be customized) | 220V(can be customized) | 220V(can be customized) |
Power | 6000W | 6000W | 50W |
Capacity | 300-1200 up to 2300pcs | 300-1200 up to 2300PC | 300-1200 up to2300PC |
Production size | 20-120mm | 20-120mm | 20-120mm |
Material | All stainless steel | All stainless steel | All stainless steel |
Number and size of molds | 3pcs/25mm,35mm,45mm | 3pcs/25mm,35mm,45mm | 3pcs/25mm,35mm,45mm |
Tank capacity | 7L | 7L | 7L |
Oil tank size | 805*310*115mm (29L) | 805*310*115mm 29L | 805*310*115mm 29L |
Fuel tank size | 845*345*125mm | 845*345*260mm | 845*345*260mm |
Conveying size | 1010*350*170mm | 1010*350*170mm | 1010*350*170mm |
Overall size | 1200*550*720mm | 1300*650*840mm | 1300*650*840mm |
No box foot packaging size | 1095*605*415mm | 1095*700*565mm | 1100*700*600mm |
net weight | 48KG | 58KG | 74KG |
Gross weight | 62KG | 78KG | 84KG |
Safety | Double temperature control | Double temperature control | Double temperature control |
