Juice Milk Paint High Pressure Homogenizer with CSA Certificate

NINGBO HAISHU JUDIN PACKING PRODUCTS CO., LTD. / 2022-07-05

Juice Milk Paint High Pressure Homogenizer with CSA Certificate

  • Process:Mild Processing
  • Power Source:Electric
  • Certification:CE
  • Automatic Grade:Semi-Automatic
  • Application:Milk, Dairy, Milk, Juice, Beverage
  • Customized:Accept

=== Base Info ===

  • Model NO.:KQ
  • Name:Juice Milk Paint High Pressure Homogenizer with CS
  • Product Material:Stainless Steel 304,316
  • Capacity:50L,H--10000L,H
  • Pressure:250bar to 700bar
  • Homogenizer Certificate:Ce, ISO
  • Homogenizer Appication:Milk , Juice, Beverage, Butter, Honey, Cream
  • High Pressure Homogenizer:Customized Electricity Motor
  • Motor:3phases
  • Homogenization Effect:to 2 Um Liquid
  • Homogenizer Working Life:More Than 10years
  • English Manual Instruction:Provide
  • Transport Package:Standard Wooden Box
  • Specification:CE
  • Trademark:KAIQUAN
  • Origin:Shanghai, China
  • HS Code:8479820090
  • Production Capacity:100 Units,Month

=== Description ===

Basic Info.

Model NO. KQ Name Juice Milk Paint High Pressure Homogenizer with CS Product Material Stainless Steel 304/316 Capacity 50L/H--10000L/H Pressure 250bar to 700bar Homogenizer Certificate Ce, ISO Homogenizer Appication Milk , Juice, Beverage, Butter, Honey, Cream High Pressure Homogenizer Customized Electricity Motor Motor 3phases Homogenization Effect to 2 Um Liquid Homogenizer Working Life More Than 10years English Manual Instruction Provide Transport Package Standard Wooden Box Specification CE Trademark KAIQUAN Origin Shanghai, China HS Code 8479820090 Production Capacity 100 Units/Month

Product Description

Juice Milk Paint High Pressure Homogenizer With CSA Certificate
300lph to 10000lph 250bar Milk Homogenizer
GJB high pressure homogenizer
Juice Milk Paint High Pressure Homogenizer with CSA Certificate

Juice Milk Paint High Pressure Homogenizer with CSA Certificate
Milk High Pressure Homogenizer, You Can Buy Various High QualityMilk High Pressure Homogenizer Products from us,  the 250bar milk homogenizer,
CE CERTIFICATED HOMOGENIZER FOR MILK, JUICE, DAIRY, ICECREAM, SOYBEAN MILK, HONEY
Soybean milk homogenizer,  40MPA homogenizer
Tea drinks homogenizer,  juice homogenizer
homogenizer pumps
             Model No.
Technical
parameter

KQ0.5-25

KQ1-25

KQ1.5-25

KQ2-25

KQ2.5-25
GJB3000-25
KQ3-25

KQ5-25
Rated pressure(MPa)25252525252525
Rated flow ( Liters/H )500100015002000250030005000
Medium temperature(C)≤85≤85≤85≤85≤85≤85≤85
Feeding pipe diameter(mm)25252525253240
Discharge pipe diameter(mm)15152020202025
Power of motor(Kw)5.57.5111518.52245

Volt and Electricity Flow220V,60HZ,3PH380V,50HZ380V,50HZ380V,50HZ220V,60HZ,3PH380V,50HZ380V,50HZ
Outline dimension (m)
Length * width * height
1.16×0.9×1.241.16×0.9×1.24

1.16×0.9×1.24

1.4×1.1×1.421.4×1.1×1.421.4×1.1×1.422.2×1.45×1.1

Weight(Tons)0.40.51.251.251.251.251.7
Juice Milk Paint High Pressure Homogenizer with CSA Certificate
Juice Milk Paint High Pressure Homogenizer with CSA Certificate
Juice Milk Paint High Pressure Homogenizer with CSA Certificate
Juice Milk Paint High Pressure Homogenizer with CSA Certificate
High pressure homogenization is a standard industrial process for dairy products, to improve their stability and shelf life
series is the kind of equipment which can homogenize the liquid material and make it become high-pressure spray. The high pressure homogenizer pump reciprocates the pump position, high press the liquid, fully mixed and refined the material.
The high pressure homogenizer can use to homogenize the dairy product material in high pressure, refine the fat globule, prevent or decrease the stratifying of the liquid material; Make the product much more nicety, to prove the quality of the product.
The high pressure homogenizer pump also the important equipment of the powder manufacture. (Such as pharmaceutical industry, chemical industry, etc. )
Juice Milk Paint High Pressure Homogenizer With CSA Certificate .
