PVC Plast- Steel Profile Making Machine for Window/Door/Door Frame

=== Base Info ===

=== Description ===
SPECIFICATIONS FOR PLASTIC-STEEL PROFILE EXTRUSION LINEModelScrew Diameter(mm)Main Moter(kw)Output Capacity(kg/h)GSZ-4545/10015/18.560/80GSZ-5151/10518.5/2280/110GSZ-5555/11022/30120/150GSZ-6565/13237/45280/350GSZ-8080/15655/77380/450GSZ-80A80/17375500/650GSZ-9292/188110/132700/850GSZ-9595/196132/1601000
Main technical parameters :
 Items Technical Parameters1. Extruder Supplier of electric control cabinetMain transducer and feeder's transducer: ABB; Air switch: Suzhou SIEMENSExtrusion capacity (kg/h)Maximum capacity is150-180 kg /hOuter Size (mm)4400mmX1600mmX2700mmTotal Weight (Kg)4100kgCenter height(mm)1050mmInlet wire terminal of power resourceThree-phase four-wire system,380V,50HZManufacture of the motors,bearings ,pumpsThe main DC motor: 45KW;
Motor for feeder: 0.55KWType of Temperature control curveTemperature fluctuating self-adjusting (PID Type)Origin places of the temperature control meters, manometers, and speedometersPLC controllerType of the conductive oilOne barrel of conductive oil is sent with the machine


For choosing the proper machine and saving your time, please read these bellow guides carefully
1). What kinds of plastic machinery do you need ? Or what material do you want to process?
2). What capacity do you want? (kg/h )
3). What is the max and min size of the finish products .For example, the width and thickness of sheet(mm)?
4) What is the electric device you need ? Siemens, Omron or domestic ?
5) When do you want the machine? (Times for delivery)
6) Other requirements about the machine you want.

if you are interested in this machine ,please contact me:
mob : +86 13817556740


Jeremy He
