Diamond Stone Cutting Disc by Turbo Hot Pressed

• Blade Type：Diamond Cutting Disc
• Manufacturing Process：Sintered
• Application：Stone
• Material：Diamond
• Segment Height：10mm
• Inner Hole Size：22.23mm

=== Base Info ===

• Model NO.：HZ-DCS
• Transport Package：Paper Box, Wooden Box, Carton, etc
• Specification：150*2.6*10*22.23mm
• Trademark：HUAZUAN
• Origin：Fujian, China
• HS Code：82023910
• Production Capacity：8000PCS,Week

=== Description ===
                                                                            Product descriptionBrand:Huazuan or OEM
Specification:

1.Size:4"-9"(105mm-230mm)
2.Segment height:8/10/12mm
3.Inner hole: 22.23mm/20mm/25.4mm/16mm

Features:
Dry/wet cut; Multi-application saw blades suitable for fast, free and smooth cutting.

Application:
Tile,bricks,brick blocks,concrete,marble,granite,stone, etc.


Machinery:
Angle grinder,circular saw,table saw, etc.Technology:sintered

Quality Control:
1. Strict Raw material inspection
2. Professional formula
3. Production process control(PDCA+7S Principle)
4. Do some cutting testing to sure the using function
5. Products pass SGS inspection
 MOQ:100PCS for each sizePayment term:TT,western union,PAYPAL etcPackage:Plastic bag/paper bag+wooden bag or custom madeDelivery:7-12 working days after receiving payment.CertificationISO9001 and SGS product quality control

There are some specifications of turbo segment diamond stone cutting disc for your reference:DiameterBoreSegmentSegment            mminchSize(mm/inch)Thickness(mm)Height(mm)           1054"20/0.787"1.88/10/12           1104.3"20/0.787"1.88/10/12           1154.5"22.23/0.875"1.88/10/12           1255"22.23/0.875"2.08/10/12           1506"22.23/0.875"2.2    8/10/121807"22.23/0.875"2.4    8/10/122008"22.23/0.875"2.4    8/10/122309"22.23/0.875"2.6    8/10/1225010"22.23/0.875"2.8    8/10/12
Application of diamond cutting disc:


Attention when use of stone cutting disc:
1.  Before saw blade installed, pollutions adhering between saw blade and flange shall be removed,
when installing saw blade, the marked direction shall be kept consistent with the rotating
direction of electric tools, and flange shall be fastened by spanner attached to electric tools
2. Do not use any saw blade that has been deformed for being pressed of crashed
3. When operating, operator must wear safety helmet, safety footwear and goggles, protective glove,additionally, if necessary operator must use earplug, mask and so on
4. Electric tools shall have protective cover
