Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W

Zech Industry Limited / 2022-06-23

Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W

  • After-sales Service:Online Service
  • Warranty:2 Years Warranty
  • Application:Biomedicine, Electronic Industry, Automotive Industry, Manufacturing Industry
  • Technical Class:Continuous Wave Laser
  • Control:Automatic
  • Power Density:Deep Fusion Welding

=== Base Info ===

  • Model NO.:XTW
  • Laser Classification:Optical Fiber Laser
  • Type:Optical Fiber Transmission Laser Welding Machine
  • Laser Source:Raycus Max Ipg
  • Welding Head:Qilin Hanwei Double Wobble
  • Chiller:Built-in
  • Touch Screen:Yes
  • Control System Language:8 Language Optional, English French
  • Auto Wire Feeder:Yes
  • Consumables:Protective Lens and Nozzles
  • Protective Glasses:Yes
  • 1kw and 1.5kw Power Required:220V, Single Phase
  • 2kw Power Required:380V
  • Fiber Optical Length:8m
  • Auxiliary Gas:N2,Argon
  • Spot Size:Spot Diameter Is Adjustable, From 0.2 to 5mm.
  • Spot Mode:6 Spot Mode Optional
  • Welidng Gun Weight:1kg
  • Transport Package:Plywood
  • Specification:143*82*135cmx280kg
  • Origin:China
  • HS Code:8515809090

=== Description ===
Overview Machine photo

Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W
Welding head is double wobble type.
6 spot mode optional:  Spot; line;"O",double"O";triangle;"8"type
spot diameter is adjustable, from 0.2 to 5mm.

Brand is optional.
For 1kw 1.5kw, Hanwei and Qilin brand.
For 2kw,Hanwei brand.
Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W
Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W

Technical date  MaterialMax welding deptNo.Machine power1kw1.5kw2kw1Stainless Steel≤2mm≤3mm≤5mm2Mild Steel/ Iron≤3mm≤4mm≤6mm3Aluminum/ brass≤2mm≤3mm≤4mm

Working videos xt laser handheld weldinghttps://youtu.be/2Yy3vZt8y2QStainless steel weldinghttps://youtu.be/2Auwmeq0q8IBrass weldinghttps://youtu.be/2kc1ijc4rJIstainless steel weldinghttps://youtu.be/fXO8B_MmjXQSamples

Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W

Detailed Photos

Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W

Packing

Machine size (L*W*H):115*62*117cm
Net Weight:260kg
Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W
Package size:143*82*135cm/71*35*48cm
Gross Weight:280kg/48kg
Package type:Ply-wood case;

Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W

Our Team and Company

Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000WMetal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W

Exhibitions

Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W
Customer Visiting
Metal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000WMetal Laser Welder Fiber Laser Welding Equipment 1000W 1500W 2000W
