Hydraulic Coffee Bean Oil Extraction Machine Camellia Oil Press
Hangzhou Xinyue New Materials Co., Ltd. / 2022-07-04
- After-sales Service:on-Line Service
- Warranty:1 Year
- Type:New-Type Hydraulic Oil Press
- Application:Beans, All Kinds of Oil Seeds
- Voltage:380V
- Appearance:Vertical
=== Base Info ===
- Model NO.:6YZ-230
- Press Materials:Cocoa Bean
- Press Series:Hydraulic Oil Press
- Condition:New
- Customized:Customized
- Capacity:45kg,H
- Model:6yz-230
- Volume of Pressing Barrel:8kg
- Power:1.5kw
- Heat Power:2kw
- Push Power:190t
- Work Pressure:55MPa
- Stroke of Piston:300mm
- Inner Pressing Barrel:230mm
- Size:870*780*1300mm
- Transport Package:Wooden Case
- Specification:ISO, SGS, CE
- Trademark:sunshine
- Origin:Henan
- HS Code:84792000
- Production Capacity:1000 Sets Per Month
=== Description ===
Model | QYZ-500 | QYZ-410 | QYZ-230 |
Working pressure | 40MPa | 45MPa | 55MPa |
Pushing force of working | 300t | 120t | 190t |
Inner diameter of pressing barrel | 500mm | 410mm | 230mm |
Working stroke of piston | 700mm | 500mm | 300mm |
Capacity of pressing barrel | 200kg | 80kg | 8kg |
Handling capacity | 200kg/h | 80kg/h | 45kg/h |
Main motor | 4kw | 1.5kw | 1.5kw |
Motor of heating | 4kw | 4kw | 2kw |
Weight | 2800kg | 1500kg | 850kg |
hydraulic coffee bean oil extraction machine camellia screw oil press has a top plunger main components, hydraulic cylinders, columns, activity on the base, table, barrel, heating ring, fixed sets, fuel tank and other components.
Capacity Oil seeds | Time/Batch | Capacity/Batch | Capacity/10hours | Oil yielding rate |
Sesame | 5-8minutes | 6-9Kg | 360-520Kg | 42%-52% |
Camellia | 8-12minutes | 6-9Kg | 260-320Kg | 25%-35% |
Walnut | 8-12minutes | 6-9Kg | 260-320Kg | 50%-60% |
Pine nuts | 8-12minutes | 6-8Kg | 310-630Kg | 45%-60% |
Suitable seeds for Low price more oil cocoa bean hydraulic oil press machine 200kg Crushing peanuts,sesame, pumpkin seeds, linseed, mountain seed, cocoa bean, coffee bean, pepper seeds, walnuts, tea seed, castor, camellia, pumpkin seeds, nuts, olive, black seed, walnut, almond and other oil crops.
RFQ
1, Which kinds of seeds your machine can press?
It can press peanuts, soybeans, rapeseed, sesame, sunflower, linseed, mountain seed, cottonseed, pepper seeds, walnuts, tea seed, castor, camellia, pumpkin seeds, nuts, olive, black seed, almond and other oil crops.
2, What is the power?
The motor is 1.5kw, good motor.
3, What is the production time?
The machines are in stock, we just need 2 days to pack the machines and send them to the port.
4. Can you provide us with operation video and English manual?
Of course, we can provide you video and manual. We can also send technician for your factory to instruct if you need.
5, What other machines we need after this machine if we want to pack the oil into bottles?
The oil is better if you get another equipment like low temperature filter process equipment. After that, you fill the oil into bottles and cap them.
If you want it to be made by stainless steel, we can also do it for you.The hydraulic oil press can press many kinds of oil seeds and nuts, such as walnuts, cocoa beans,
sesame, avocado, sunflowers, almonds, peanuts/groundnuts, walnuts, cashew nuts, tea-seeds, coconut, pinenut, hazelnut, sacha inchi seeds, macadamia nuts, moringa kernel, pumpkin seeds kernel, etc.Details pictures:
Item | Picture |
Oil seeds for oil machine | |
Oil machine | |
Specific oil machine | |
Oil machine | |
Oil machine in Workshop | |
Wooden case package | |
