Fiber Laser Marker with Raycus Fiber Source 20W (DW-F20W)

• Laser Visibility：Visible
• Applicable Material：Metal
• Cooling System：Air Cooling
• Technical Class：Fiber Laser Marking Machine
• Laser Wavelength：Fiber Laser
• Laser Classification：Fiber Laser Marking Machine

=== Base Info ===

• Model NO.：DW-F20W
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Working Size：100*100mm,150*150mm,200*200mm,300*300mm
• Laser Power：20W
• Graphic Format Supported：Ai, BMP, Dst, Dwg, Dxf, Plt
• Max. Linear Marking Speed：9000mm,S
• Laser Module Life：100000 Hours
• Marking Depth：0.01mm-0.05mm(According The Material)
• Frequency：20kHz-100kHz
• Cooling Mode：Air Cooling
• Marking Linear Deep：1.2mm
• Transport Package：Plywood Box, Free of Fumigation
• Specification：CE, FDA
• Trademark：DWIN
• Origin：Jinan City, Shandong Province
• HS Code：8456100090
• Production Capacity：50 Sets,Month

=== Description ===

Basic Info.

Model NO. DW-F20W Type Optical Fiber Laser Marking Machine Marking Method Scanning Marking Working Size 100*100mm/150*150mm/200*200mm/300*300mm Laser Power 20W Graphic Format Supported Ai, BMP, Dst, Dwg, Dxf, Plt Max. Linear Marking Speed 9000mm/S Laser Module Life 100000 Hours Marking Depth 0.01mm-0.05mm(According The Material) Frequency 20kHz-100kHz Cooling Mode Air Cooling Marking Linear Deep 1.2mm Transport Package Plywood Box, Free of Fumigation Specification CE, FDA Trademark DWIN Origin Jinan City, Shandong Province HS Code 8456100090 Production Capacity 50 Sets/Month

Product Description

                      Fiber Laser Marker with Raycus fiber source 20W (DW-F20W)

Features:

1.It is the third Generation laser marking system which is used the most advanced fiber laser technology.

2.Longest lifetime for marking machine seried,100000hours free of maintenance ,stable performance,high laser energy,can engraving on all the metal materials and some of nonmetal materials.

3.Location by red light,testing and changing holder will be easier.

4.Adopt air cooling system and the size is small,good quality of the laser beam,suitable for precise strips pattern marking.

Application materials:

The fiber laser machine can marking metal(including the rare metals) such as steel, titanium,copperetc,and some of nonmetal such as nylon,light button, ABS, PVC,PES

Application area:

The area with the higher requirement foor depth,smoothness and degree of thickness such as clock industry,mould industry,bitmap marking and so on.the other area such as electroni compnent,eletrical prducts.IT industry,auto partas,metal tools,accurate instruments,present and adornment,medical instrument,high or low voltage electric equipment and so on.

Technical Parameters:


Model	DW-F-10W	DW-F-20W
Laser wave	1064nm	1064nm
Laser power	10w	20w
Frequency	20KHZ-100KHZ	20KHZ-100KHZ
Max marking speed	9000mm/s	9000mm/s
Marking depth	0.01mm-0.3mm(according the materials)	0.01mm-0.5mm(according the materials)
Repetition precision	0.002mm	0.002mm
Working size	100*100/150*150/200*200 /300*300mm	100*100/150*150/200*200/300*300mm
mini line width	0.01mm	0.01mm
Cooling way	Air cooling	Air cooling
