High Quality Cheap 3000L Conical Fermenter Stainless Steel Wine Beer Fermentation Tanks

• Condition：New
• Customized：Customized
• Voltage：110V-480V Customized
• Composition：Fermentation Tank
• Processing Material：Special Agricultural Products, Malt,Yeast,etc
• Process：Ferment

=== Base Info ===

• Model NO.：HG-3000L
• Model：Hg-Fj-3000L
• Capacity：3000L
• Material：SUS304
• Application：Restaurant, Bar, Hotel, Brewery
• Cooling Method：Jacket Section Cooling
• Thickness：Inner:3.0mm; External2.0mm
• Outrigger：102mm*4
• Insulation：100mm
• Working Pressure：0.09MPa
• Heat Exchange Area：4.5m2
• Height：3800mm
• Transport Package：Plywood Case by LCL or Container by FCL
• Specification：3000L
• Trademark：HG
• Origin：Shandong
• HS Code：8419899090
• Production Capacity：20 Sets,Month

=== Description ===

Basic Info.

Model NO. HG-3000L Model Hg-Fj-3000L Capacity 3000L Material SUS304 Application Restaurant, Bar, Hotel, Brewery Cooling Method Jacket Section Cooling Thickness Inner:3.0mm; External2.0mm Outrigger 102mm*4 Insulation 100mm Working Pressure 0.09MPa Heat Exchange Area 4.5m2 Height 3800mm Transport Package Plywood Case by LCL or Container by FCL Specification 3000L Trademark HG Origin Shandong HS Code 8419899090 Production Capacity 20 Sets/Month

Product Description

Model	HG-FJ-3000L
Gross capacity	3750L
Useful capacity	3000L
Thickness	Inner (SUS304)thickness: 3.0mm; External-Jacket(SUS304) thickness: 2.0mm
Material	Stainless steel 304
Cooling way	Dimple jacket plate
Cleaning way	CIP in situ cleaning, with rotary spray cleaning ball
Insulation	Polyurethane-thickness: 100mm
Accessories	Sample valve, Pressure gauge, Breath valve, Temperature gauge, Top manhole, Washing ball, Butterfly valves, CIP Arm, Hop port, Discharge arm and so on.

Product advantages :
1. 304 stainless steel plate as a whole, and our stainless steel plate manufacturer is the best in China
2. The cooling efficiency of Maitreya plate jacket is greatly improved.
3. Two stage cooling mode.
4. The insulation layer material is high-grade polyurethane with a thickness of 80mm.
5. Polishing accuracy up to Ra0.4μ m.
6. Strict tank pressure test.
7. Energy conservation and pollution emissions.

The fermentation tanks use certified stainless steel material. All tanks and jackets inspected and pressure
tested to 3 times operatiing pressure. The dimension of the tanks can be designed according to customer's
requirement. Tank design pressure is 0.4Mpa and testing pressure is 0.3Mpa.






Item	Production capacity	Volume in US Gallon	Heating area	Tank diameter	Height
HG-100	100L/day	26US Gallon	0.5m2	650mm	1500mm
HG-200	200L/day	53US Gallon	0.8m2	850mm	1600mm
HG-300	300L/day	79US Gallon	1.2m2	960mm	1700mm
HG-400	400L/day	106US Gallon	1.5m2	1060mm	2000mm
HG-500	500L/day	132US Gallon	1.8m2	1160mm	2300mm
HG-5BBL	5BBL/day	155 US Gallon	1.9m2	1200mm	2350mm
HG-600	600L/day	158US Gallon	2.0m2	1220mm	2350mm
HG-700	700L/day	185US Gallon	2.4m2	1260mm	2380mm
HG-800	800L/day	212US Gallon	2.5m2	1260mm	2400mm
HG-7BBL	7BBL/day	216US Gallon	2.5m2	1280mm	2450mm
HG-1000	1000L/day	264US Gallon	2.6m2	1360mm	2500mm
HG-10BBL	10BBL/day	310 US Gallon	2.8m2	1460mm	2700mm
HG-1500	1500L/day	396US Gallon	3.2m2	1520mm	2900mm
HG-2000	2000L/day	528US Gallon	3.6m2	1560mm	2850mm
HG-2500	2500L/day	660US Gallon	3.8m2	1650mm	3200mm
HG-3000	3000L/day	792US Gallon	4.5m2	1760mm	3800mm
HG-4000	4000L/day	1057US Gallon	4.9m2	1900mm	4100mm
HG-5000	5000L/day	1320US Gallon	7.2m2	1960mm	4400mm

Our service

1.Pre-service:
-Layout:Sent us your building floor plan, or the sketch, or tell us the size (length, width, height), we will offer you an equipment footprint according to your requirement.
-Technical Drawings : We will offer Technical Drawings of each tank based on the equipment layout .
-3D effective sketch: We will 3D effective sketch to make sure ensure you have a more intuitive experience
2.After service
We guarantee the quality of the electrical elements within 1year and tanks body within 1 years. If the electrical elements go wrong without artificial factors within one year, we will freely provide them or maintain them for you.
After warranty, if you need to change parts, we will kindly provide you with the best price or maintain it in your site. Whenever you have technical question in using it, we will freely do our best to support. We can also dispatch our engineer to your brewery to install and adjust the machines for you. He can also train your staff to use the equipment.


FAQ

1.Q:Does your company have foreign installation experience?
A: Yes, our company has installation experience in USA, Canada, Europe, Australia, Malaysia, Myanmar, South Africa etc.
2.Q: Do you have a professional engineer or after-sales team in our country?
 A: Yes, our equipment is sold to 150 countries and areas and we have our local after-sales service personnel in Europe, America and Asia.
3.Q: How long is the delivery time?
A: The delivery time of beer equipment is 30-50 working days, the delivery time of filling machine is 45-50 working days.
4.Q:What payment methods are supported?
A:T/T, L/C, Credit Card, VISA, Apple device, Western Union.
5. Q: How long the warranty will be?
A: 3 years warranty for the whole tank and the main equipment, 1 year for the accessories and auxiliaries. 1 Year warranty for filling machine.
6. Q:How about the installation and training?
A:We can supply the installation and training. There are two options. The first option: We could appoint our engineer to your company to debug and repair, as for the cost of this trip such as ticket, visa, accommodation and labor cost shall be on your side. The second option: On-line service will be provided. If still under guarantee period, the necessary accessories and parts will be provided free, the buyer afford the transportation cost.
7.Q: Can I be your company's sales agent?
A: Yes, it's our pleasure. We very much welcome you to join us. Please contact us to discuss specific details.
