Single Screw 50 PE/LDPE/HDPE/LLDPE Film Blowing Machine

=== Base Info ===

=== Description ===

Basic Info.

Model NO. YN-700 Machine Weight 12T Transport Package Wooden Box Specification 12CBM Trademark 000 Origin Zhejiang HS Code 8477301000 Production Capacity 240

Product Description

YN-50,55,60,65 PE/LDPE/HDPE/LLDPE FILM BLOWING MACHINE

Technology Parameter

TYPE MODEL	YN-700	YN-900	YN-1100	YN-1350
SCREW DIA.	Φ50	Φ55	Φ60	Φ65
MATERIAL TO BE USED	PE/LDPE/HDPE/LLDPE	PE/LDPE/HDPE/LLDPE	PE/LDPE/HDPE/LLDPE	PE/LDPE/HDPE/LLDPE
SCREW RATIO L/D	30/1	30/1	30/1	30/1
SCREW SPEED	15-100r/min	15-100r/min	15-100r/min	15-100r/min
MAIN MOTOR POWER	15 KW	18.5 KW	22.5 KW	30 KW
MAX.EXTRUSION OUTPUT	50 kg/h	60 kg/h	70 kg/h	90 kg/h
RANGE OF DIE	Φ80Φ100	Φ100Φ120	Φ120Φ200	Φ150Φ220
THICKNESS OF FILM	0.008-0.10mm	0.008-0.10mm	0.01-0.10mm	0.01-0.10mm
MAX FOLDING WIDTH OF FILM	600mm	800mm	1000mm	1200mm
ELECTRIC TOTAL CAPACITY	24kw	30kw	38kw	46kw
DIMENSION(LxWxH)(m)	3x2.5x4.2	3.2x2.8x4.5	3.8x3.5x5	4.2x3.8x5.2
WEIGHT OF MACHINE	2.5T	3.0T	3.5T	3.8T



Welcome to contact  us for more details and prices!!!





WENZHOU BROTHER UNION MACHINERY CO.,LTD.

Cellphone:0086-18367752517 (Gloria Lin)
Telephone:0086-0577-66611121

Address:Ruian City, Zhejiang, China
