Convenient Mobile Crawler Water Well Drilling Rig From China

Zhejiang Huawei Machinery Co., Ltd. / 2022-06-23

Convenient Mobile Crawler Water Well Drilling Rig From China

=== Base Info ===

=== Description ===

Basic Info.

Model NO. JK-DR 600 Type Crawler Usage Water Well Voltage 24V Weight 12t Warranty 1 Year Power Type Diesel Product Name Water Well Drilling Rig Power 132kw Transport Package 40hc Specification 6000*2200*2850mm Trademark SDJK Origin Shandong HS Code 8430412100 Production Capacity 100sets/Month

Product Description

JK-DR600 Multifuncational Water Well Drilling Rig For SaleConvenient Mobile Crawler Water Well Drilling Rig From China
Convenient Mobile Crawler Water Well Drilling Rig From China
Convenient Mobile Crawler Water Well Drilling Rig From China
Model & NameJK-DR600
Weight  12Ton
Dimensions(mm)6200*2200*2950mm
Power OilDiesel
Engine ModelYUCHAI
Rated Power132 kW
Travelling SystemSteel Crawler
Drilling depth  600m
Bore diameter 140-350mm
Drive Head Stroke6.6m
Travelling speed2.5km/h
Gradeability30%
Rated pressure1.7-3.5 MPa
Air consumption17-42 m³/min
Drill rod diameter  Φ102 / Φ108/ Φ114 mm
Drill rod length 1.5m, 2.0m, 3.0m, 6.0m
Elevating capacity 28 Ton
Winch Elevating capacity3 Ton
Swing speed 45-115rpm
Swing torque   8500-11000 N.m

Convenient Mobile Crawler Water Well Drilling Rig From China
Convenient Mobile Crawler Water Well Drilling Rig From China

1. The engine uses YUCHAI 132 KW turbocharged engine;
2. Walking Type: crawler mounted ,trailer mounted for choice.
3. Hydraulic oil pump:Parallel gearbox design separates the oil pump unit, the power supply is adequately distributed, the hydraulic system is uniquely designed, and the maintenance cost is small;
4.Rotary head device:gearbox integrated casting, dual motor power, large torque, durable, low maintenance costs;
5.Drilling machine chassis:professional digging chassis, durable, heavy bearing, wide chain plate, less damage to hard roads;
6.Lifting force:design composite tower, 6.6m long stroke, double cylinder lift capacity 28 ton.
7. Each rig is equipped with a relief valve to raise the boom to protect the cylinder and ensure work safety;
8. Each hydraulic oil pipe is covered with a protective jacket to make the oil pipe last longer.
Convenient Mobile Crawler Water Well Drilling Rig From China
Convenient Mobile Crawler Water Well Drilling Rig From China
Convenient Mobile Crawler Water Well Drilling Rig From China
Convenient Mobile Crawler Water Well Drilling Rig From China
Convenient Mobile Crawler Water Well Drilling Rig From China
Convenient Mobile Crawler Water Well Drilling Rig From China
Convenient Mobile Crawler Water Well Drilling Rig From China
