Operation Instruction:
1. Please add water when you start to use it .
2. Please preheat before the machine start to work, check whether it's 38ºC or not, if not,pls set it to be 38ºC according to Press-button Instruction.
3. Please check whether the two LED lights are on or not .
4. Please turn off the power after preheating. Fill the water pan with water, put it under the egg tray and put eggs into egg tray, then put on the lid of machine and turn on power.
Press-button Instruction:
A: "set" --- Temperature setting button. Press "set" once to do temperature settings, Press "+" or "-" to adjust temperature, push "set" again to save data and exit.
B. "+" --- Press it to increase temperature
C. "-" --- Press it to decrease temperatu
Instruction of indicating lamp condition:
"work" on the right side of display screen is working indication lamp . LED lighting means the machine is in working condition.
"set" on the left side of display screen is temperature setting indicating lamp, LED lighting means it's in temperature setting condition , when flashing, it means low temperature, the machine will start to increase temperature .
Number | Symbol | Meaning | Factory Setting |
3.1 (above) | AL | Low temperature alarm parameter setting | 1 o C |
3.2 (above) | AH | Higher temperature alarm parameter setting | 1 o C |
4.1 (above) | AS | Low humidity alarm parameter setting | 45% |
5.1 (above) | CA | Calibrating the temperature sensor reading | 0 o C |
6 (above) | HS | Temperature higher limit set | 39.5 o C |
6 (above) | LS | Temperature lower limit set | 30 o C |
7 (above) | HU | Heating starts | 18 |
7 (above) | HD | Heating stops | 11 |
Model | Chicken eggs | Duck eggs | Bird eggs | Ostrich eggs | Goose eggs | Weight /kg | Volume / CBM | Packing size/ cm |
YZTIE-1 | 24 | 15 | 54 | 7 | 23 | 0.21 | 50*51*81 | |
YZTIE-2 | 48 | 30 | 117 | 15 | 30 | 0.25 | 60*51*81 | |
YZTIE-3 | 88 | 63 | 221 | 32 | 40 | 0.39 | 73*62*86 | |
YZTIE-4 | 176 | 126 | 442 | 64 | 43 | 0.44 | 73*62*96 | |
YZTIE-5 | 264 | 189 | 663 | 6 | 96 | 46 | 0.48 | 73*62*106 |
YZTIE-6 | 352 | 252 | 884 | 128 | 52 | 0.53 | 73*62*116 | |
YZTIE-7 | 440 | 315 | 1105 | 160 | 55 | 0.58 | 73*62*126 | |
YZTIE-8 | 528 | 378 | 1326 | 12 | 192 | 59 | 0.77 | 98*74*106 |
YZTIE-9 | 880 | 630 | 2210 | 24 | 306 | 75 | 0.97 | 98*74*136 |
YZTIE-10 | 1056 | 756 | 2652 | 432 | 85 | 1.32 | 121*78*139 | |
YZTIE-11 | 1232 | 882 | 3094 | 504 | 100 | 1.43 | 121*78*151 | |
YZTIE-12 | 1408 | 1008 | 3536 | 36 | 576 | 105 | 1.57 | 121*78*166 |
YZTIE-13 | 1584 | 1134 | 3975 | 624 | 115 | 1.76 | 139*91*139 | |
YZTIE-14 | 1848 | 1323 | 4641 | 54 | 728 | 123 | 1.91 | 139*91*151 |
YZTIE-15 | 2112 | 1512 | 5304 | 832 | 133 | 2.1 | 139*91*166 | |
YZTIE-16 | 2464 | 1764 | 5967 | 72 | 1008 | 143 | 2.3 | 139*91*176 |
YZTIE-17 | 2640 | 1890 | 6630 | 1024 | 150 | 2.4 | 139*91*186 | |
YZTIE-18 | 2816 | 2016 | 7072 | 1040 | 165 | 3.1 | 182*91*186 | |
YZTIE-19 | 3168 | 2268 | 7956 | 96 | 1296 | 175 | 3.3 | 182*91*196 |
YZTIE-20 | 3520 | 2520 | 8840 | 1440 | 185 | 3.5 | 182*91*206 | |
YZTIE-21 | 3872 | 2772 | 9724 | 1584 | 195 | 3.6 | 182*91*216 | |
YZTIE-22 | 4224 | 3024 | 10128 | 108 | 1728 | 205 | 3.8 | 182*91*226 |
YZTIE-23 | 4576 | 3276 | 10608 | 1872 | 215 | 4 | 182*91*236 | |
YZTIE-24 | 5280 | 3780 | 11492 | 144 | 2160 | 220 | 3.8 | 186*102*197 |
YZTIE-25 | 8448 | 6048 | 13260 | 3456 | 440 | 8.7 | 110*186*212*2 | |
YZTIE-26 | 9856 | 7056 | 24752 | 336 | 4032 | 460 | 9.3 | 110*186*227*2 |
YZTIE-27 | 12672 | 9072 | 31824 | 5184 | 660 | 13.1 | 110*186*212*3 | |
YZTIE-28 | 14784 | 10584 | 37128 | 6048 | 680 | 14 | 110*186*227*3 | |
YZTIE-29 | 16896 | 12096 | 42432 | 504 | 6912 | 700 | 14.6 | 110*186*237*3 |
YZTIE-30 | 19712 | 14112 | 47264 | 8064 | 900 | 18.6 | 110*186*227*4 | |
YZTIE-31 | 22528 | 16128 | 56576 | 672 | 9216 | 1000 | 19.4 | 110*186*237*4 |
Temperature display range | 5_50° C |
Temperature measurement control accuracy | ± 0.1° C |
Temperature control accuracy | ≤ ± 0.1° C |
Humidity dislay range | 0-99%RH |
Humidity precision control | ± 5%RH |
Over egg cycle | 0.1--99.9hour(Factory settings 1.5hour) |
Eggs over time | 1-255 seconds adjustable (factory set to 180 seconds) |
Output current | Temperature Control 220V 10A, the other 200V 1A |
Doubled the number of eggs | Maximum record 999 times |
Operating voltage | AC180V_240V, 50Hz |
Relative humidity | Less than 85% |
Ambient temperature | -10° C--40° C |
