Parallel Twin Screw Water Ring Pelletizing Line

=== Base Info ===

=== Description ===

Basic Info.

Model NO. SHJ-65B Machine Name Parallel Twin Screw Water Ring Pelletizing Line Capacity 120-250kg/Hr Power Supply 380V 3phase 50Hz Water Consumption 3-8bar Air Consumption 5-8bar Material PP/PE/Pet/ABS Dimension 18*5*6m Operator 2-3person /Shift Warranty 12monthes Transport Package PE Elastic Film or Wooden Case Specification As per customer′s request Trademark WEIER Origin Qingdao city Shandong province, China HS Code 84772090 Production Capacity 100sets/Year

Product Description

Parallel twin screw water ring pelletizing line

Water ring pelletizing line use parallel twin extruder. Screw use buliding block system design. According to material system and technology formula requirement, make the suitable L: D, barrel structure and screw order.
Water ring pelletizing machine use new decelerater driving system. High torque design, high precesion gear processing. Can execute the material conveying, plastify, cut, disperse, even, homogenize, exhaust, etc.
Suitable material: PP PE PET EVA ABS etc.

Model	Screw diameter mm	L/D	Driving motor Kw	Screw Max.speed rpm	Output  kg/h
SHJ-65	65	36 or 40/1	55kw	500/600	80-200
SHJ-72	72	36 or 40/1	90kw	500/600	150-350
SHJ-90	90	36 or 40/1	250kw	500/600	500-800
