Perfect Laser-180W 260W 300W 400 Watts Flat Carton Cardboard Craft Label Sticker Wood Plywood MDF Die Board Laser Cutters Pressing Cutting Machines Price

• Application：Advertising Industry
• Cooling System：Water Cooling
• Technical Class：Continuous Wave Laser
• Applicable Material：Nonmetal
• Structure Type：Gantry Type
• Laser Classification：Fluid Laser

=== Base Info ===

• Model NO.：PEC-1325
• Laser Technology：Laser Vapor Cutting
• Max. Output Power：400 Watts , 600watts
• Working Area：1200 × 1800mm
• Cutting Speed：7-12mm,S
• Cutting Accuracy：0.1mm
• Servo Motor：Leadshine
• Cooling Method：Water Cooling
• Focus Mode：Auto Focus Adjustment
• Screw Guide：Taiwan Tpi
• Chill Power：1.3kw
• Support Image Format：Dst,Ai,Plt
• Transport Package：Professional Wooden Case
• Specification：173*170 *76cm
• Trademark：Perfect Laser
• Origin：Wuhan China
• HS Code：8456110090
• Production Capacity：5000PCS Per Year

=== Description ===

Basic Info.

Model NO. PEC-1325 Laser Technology Laser Vapor Cutting Max. Output Power 400 Watts / 600watts Working Area 1200 × 1800mm Cutting Speed 7-12mm/S Cutting Accuracy 0.1mm Servo Motor Leadshine Cooling Method Water Cooling Focus Mode Auto Focus Adjustment Screw Guide Taiwan Tpi Chill Power 1.3kw Support Image Format Dst,Ai,Plt Transport Package Professional Wooden Case Specification 173*170 *76cm Trademark Perfect Laser Origin Wuhan China HS Code 8456110090 Production Capacity 5000PCS Per Year

Product Description

Perfect Laser-180w 260w 300w 400 Watts Flat Carton Cardboard Box Paper Craft Label Sticker Wood Plywood MDF Die Board Laser Cutters Pressing Cutting Machines Price

(Model:PEC-1325)
Contact:Lucy

Description:
Perfect Laser has launched a fully automatic single head Die Board Laser Cutting Machine for the packaging and mold industry. It can cut 20-25mm thick wooden die board at a time with its powerful laser source.
Compared to traditional sawing machine's cutting, the advantages of this wooden laser die board cutting machine are obvious. The working area is 1200×1800mm, the speed is 7-12mm/second, the cutting thickness of this laser die board cutting machine can reach up to 25mm, which can greatly improve the production efficiency.
The wood die cut machine is easy to operate and the knife gap is even. It is an upgraded version of the double-head coaxial laser die board cutting equipment.



Applied Field:

1.Applicable materials:
The laser die board cutting machine is mainly used in the cutting of 20-25mm thick die board, wooden plate, MDF, bamboo, 10-20mm acrylic sheet, plexiglass, 1-3mm carbon steel or iron plate.

2.Applicable industry:
The laser die board cutting machine is mainly used in the die mold and packaging industry.

Features:

1. The body of our laser die board cutting machine is welded with square steel pipe with 1.7 tons weight, so it is durable and not easy to deform.
2. The spark is very small during operation and the laser die board cutting machine is configured with an exhaust fan to suck off the smoke.
3. The working precision of our laser die cutting equipment is 0.1mm, so the cutting error is small and the precision is high.
4. This laser die board cutting machine adopts arrow-shaped copper column working platform. Compared to the ordinary flat platforms, it can not only reduce the support resistance but also can reduce the blackening of the cutting surface because of the copper column's better reflection effect of the laser.
5. The laser die board cutting machine adopts fixed optical path instead of the cutting head, the X-axis and Y-axis platform can move when cutting. The laser die board cutting equipment can cut through the wooden board at a time and the cutting slit is evenly straight.



Technical Parameters:

Product Name	Laser Die Board Cutting Machine
Model	PEC-1218P
Laser Tube	CO2 sealed glass tube × 3 pcs
Max. Output Power	400 Watts / 600Watts
Working Area	1200 × 1800mm
Cutting Speed	7-12mm/s
Cutting Thickness	20-25mm wooden die board,MDF 10-20mm acrylic sheet, 1-3mm carbon steel,Iron
Cutting Accuracy	0.1mm
Servo Motor	Chinese Top brand: Leadshine 1.5KW × 2pcs
Knife Slit	0.45mm/0.71mm/1.07mm(adjustable)
Cooling Method	Water cooling
Focus Mode	Auto focus adjustment
Screw Guide	Taiwan TPI
Chill Power	1.3KW
Exhaust Fan Power	1.1KW
Machine Power	10KW
Power Supply	220V
Floor Space	4500 × 4500mm
Support Image Format	DST,AI,PLT
Warranty	12 months for whole die board laser cutting machine, 10 months for laser tube



Our Services:

* 2 year guarantee for main machine (People damaged are charged).
* Full technical support by e-mail, call and video
* Lifelong maintenance and spare parts supply.
* Free design of fixtures as customers required.
* Free training installation and operation for the staffs.



FAQ:

Q: What's the package?
A: We have 3 layers package. For the outside, we adopt wood craft case. In the middle, the machine is covered by foam, to protect the machine from shaking. For the inside layer, the machine is covered by thickening plastic bag for waterproof.



Q: Will the package damaged during transportation?
A: Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe tranportation. We have exported to 180 countries worldwide. So please don't worry, you will receive the parcel in good condition.



Q: How to install and run the machine?
A: Our technician have installed the machine before shipping. For some small parts installation, we will send detail training video, user's manual along with the machine. 95% customers can learn by themselves.



Q: How can I do if the machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.



Questions

1. What's your cutting thickness? such as 16mm, 18mm, 20mm, 25mm

2. What power you prefer? such as 300w, 400w, 1000w

3. Is the machine urgent for you? if urgent, we will make early arrangement for you in advance. Pls kindly advise.
Company Information:
Perfect laser Co. Ltd. (China) was founded in 1995, located in the core area of "China Optic Valley" - Wuhan city. Occupied with 3000 m2 ground, including R&D building and production area. It has more than 180 employees, most of them are with a bachelor degree or even a doctorate degree. Executed by reliable quality and reasonable price, our products get favorable sales success and outstanding reputation not domestically in China but also popular in more than 180 countries such as the USA, Italy, Korea, Singapore, Poland, Turkey, Sweden, Saudi Arabia to worldwide.

ContactPerfect Laser Co., Ltd. (China)Contact: Lucy / Sales DepartmentAdd: HengRuichuangzhi Technology Park, No.13 YangQiaohu Road, Jiangxia District, Optical Village, Wuhan, Hubei, China(430200).Tel: 0086-27-86791986  MP: 0086-13659899108  Fax: 0086-27-86775865
