SPECIFICATION FOR SPVC SAME DIRECTION PARALLEL TWIN-SCREW PELLETING LINE
| Model | Output capacity(kg/h) | Applicable raw materials |
GTP65 | 65/44 | 200-300 | PE,PP SPVC,ABS PC,Engineering Plstics |
GTP75 | 75/40/44 | 400-600 |
GTP95 | 95/40/44 | 800-1000 |
SPECIFICATION FOR PP SINGLE SCREW PELLETING EXTRUSION UNITS
| Model | Output capacity(kg/h) | Applicable raw materials |
GW65 | 65/34 | 80 | PE PP PS ABS |
FW90 | 90/34 | 150 |
GW120 | 120/34 | 250 |
GW150 | 150/34 | 380 |
SPECIFICATION FOR PP CONICAL TWIN-SCREW PELLETING EXTRUSION LINE
| Model | Output capacity(kg/h) | Applicable raw materials |
GSZ65 | 65/132 | 300 | PVC PE+WOOD PP+CaCo3 |
GSZ80 | 80/156 | 500 |
GSZ92 | 92/188 | 900 |
The line is for SPVC pelletize.- Material: 40%PVC+32%CaCO3+28%DOP
- Capacity:
Extruder Type | Material | Capacity | Remark |
GSP120/26 | 40%PVC+32%CaCO3+28%DOP | 400-600kg/h | |
The output capacity varies with the materials and the operation conditions.- The height of the centerline of the line: 1300mm
- Operation direction: From right to Left
- The color of the line: According to GPM's standard
- GPM remains the right to improve the specification of the line, if there is any modification in the future, customer will not be informed.
