Fully Automatic Plastic Bottle Making Machine / Bottle Blowing Machine

=== Base Info ===

=== Description ===
Machine Configurations:
a). PLC: DELTA (Taiwan)
b). Cylinder: Air TAC (Taiwan)/ FESTO (Germany)
c). Valve: FESTO (Germany)
d). Relay: IEDC (Japan)
e). Photoelectric switch: AUTONICS (Korea)
f). All the components are selected with international advanced high-tech products.

Fully Automatic Plastic Bottle Making Machine / Bottle Blowing Machine
Machine Features:
1).High Intelligence:The machine can be controlled through touch screen and running status is shown on it.
2).High Quanlity:Steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.
3).High Speed:1000BPH
4).No Contamination:Closed production zone, good self-lubrication system avoid contamination.
5).Low Cost:Low consumption of electricity, air and water.
6).High Transparency:Easy maintenance, absolute safely, visual inspection, low noise. Machine Specifications:

MOLDING	Clamping force	kg	1600
	Clamping stroke	mm	125
	Stretching stroke	mm	350
	Bottom Stroke	mm	30-70
	Cavity pitch	mm	120
	Number of Cavity	Cavities	2
CONTAINER	Max.container volume	itr	1.5
	Neck diameter range	mm	18-38
	Max.container diameter	mm	115
	Max.container height	mm	320
	Carriage unit	pcs	58
THEORETICAL OUTPUT		bph	2400
ELECTRICAL SYSTEM	Total power	kw	30
	Heating power	kw	10
	Max.heating power	kw	24
AIRSYSTEM	Operating pressure	kg/cm2	7
	Air consuming	Itr/min	1000
	Blowing pressure	kg/cm2	35
	Air consuming	Itr/min	3200
AIR DRYER	Operating pressure	kg/cm2	2-4
	Temperature		10-12
	Consuming	kcal/hr	5400
	Flow rate	Itr/min	30
WATER CHILLER	Operating pressure	kg/cm2	2-4
	Temperature		30
	Consuming	kcal/hr	39000
	Flow rate	Itr/min	130
MACHINE	Machine size	mm	1950-1750-2200
	Machine weight	kg	2800
REMARKS	1. All data standard infication for0.6L bottle.  2. The actual output depends on the preform quality and boltte shape. 3. Specifications are subject to change without notice.  4. Please provide the stable ambient temperature.
