Linear 1gallon 3gallon 5gallon Barrel Water Filling Machine

• Condition：New
• Customized：Customized
• Voltage：380V
• Composition：Filling Machine
• Processing Material：Natural Ingredients
• Process：Thermal Processing

=== Base Info ===

• Model NO.：NC
• Export Markets：Global
• Name：1 Gallon 10L Water Filling Bottling Machine Linear
• Structure：Linear
• Transport Package：Wooden Case
• Specification：2400*1650*2500
• Trademark：NanCheng
• Origin：China(Mainland)
• Production Capacity：10sets,Year

=== Description ===

Basic Info.

Model NO. NC Export Markets Global Name 1 Gallon 10L Water Filling Bottling Machine Linear Structure Linear Transport Package Wooden Case Specification 2400*1650*2500 Trademark NanCheng Origin China(Mainland) Production Capacity 10sets/Year

Product Description

main charateristic
1. Pure water production equipment imported reverse osmosis membrane, desalination rate is high, long service life, low operating costs;
2. Using automatic pretreatment system, realizes the unmanned operation;
3. Adopt nanfang special pump industry pump, high efficiency, low noise, stable and reliable;
4. Pure water production equipment on-line water quality monitoring control, real-time monitoring of water quality change, to ensure the safety of water quality;
5. Automatic control program, also optional touch screen operation, easy to use;
6. Suit the local water personalized design, all-round meet the demand.
Automatic filling JiGuan machine characteristics
Filling machine is for 3 gallons, 5 gallons bottled drinking water production.The machine combines washing, filling and capping functions in an organic whole.It is an ideal equipment of mineral water, distilled water, pure water production.Whole USES the high quality stainless steel, corrosion resistance, easy to clean.The original main electric adopts SIEMENS, OMRON France TE products, pneumatic system adopts famous brand product.This machine structure is compact, small occupied area, high efficiency operation is stable and reliable, high degree of automation.Is less operators, machine, electricity, gas automatic equipment in the trinity.Totally enclosed stainless steel structure, electric operation microcomputer logic program control disposable aseptic filling.
1. Suitable for bottle type: only 3 gallons, 5 gallons of water supply of bottled drinking water production.
2. The function is all ready, the machine combines washing, filling and capping functions in one body.
3. The scope of application: is the ideal equipment for the production of mineral water, distilled water, pure water
manufacturing technique
Pure water main production process including pretreatment, reverse osmosis, disinfection, sterilization, etc., can effectively remove the impurities in the water, bacteria, such as heat source.In beverage, food, dairy industry production process with purified water in addition to the conventional purification treatment, will also adopt super LvJingHua system, make water quality more high quality, effective protection of reverse osmosis pure water system.[2] pure water plant using ultrafiltration system at the core of the process using ultrafiltration membrane separation technology, the advantage of its unique properties can be widely used in tap water, surface water, well water and sea water in addition to bacteria, in addition to the colloid, in addition to the suspended particles.After dealing with the ultrafiltration membrane in addition to the material, crystal clear water, meet the needs of the industrial water.Membrane module in industrial water treatment system, can be used in RO reverse osmosis water pretreatment system, makes the water SDI values conform to the requirements of the water of reverse osmosis membrane, prolong the service life of reverse osmosis membrane, improve the water quality of reverse osmosis water.

Model	QGF-100	QGF-300	QGF-450	QGF-600	QGF-900	QGF-1200	QGF-2000
Filling heads	1	2	3	4	8	12	16
Volume(L)	18.9	18.9	18.9	18.9	18.9	18.9	18.9
Barrel size(mm)	Φ270*490	Φ270*490	Φ270*490	Φ270*490	Φ270*490	Φ270*490	Φ270*490
Capacity(b/h)	100-120	200-240	300-400	600	900	1200	2000
Gas pressure(mpa)	0.4-0.6	0.4-0.6	0.6	0.6	0.6	0.6	0.6
Gas consumption(m3 /min)	0.37	0.6	0.6	1.2	2.2	3	4.5
Motor power(kw)	1.75	3.22	4.8	8.5	8.5	8.5	8.5
Rated voltage(V)	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz	380V/50Hz
Overall dimension(LxWxH)(mm)	3790*650*1550	3550*800*1800 2800*1100*1800	3550*1200*1800 3800*1100*1800	3650*1500*1800 3800*1100*1800	2200*1860*2700 Without cleaning	2560*2350*2750 Without cleaning	3100*2800*2750 Without cleaning
Weigt(kg)	800	2800	4000	5500	7500	9500	11800
