Plastic Bags Shredder Film Shredder

Shanghai Hampool Enterprise Co., Ltd. / 2022-07-04

Plastic Bags Shredder Film Shredder

=== Base Info ===

=== Description ===

Basic Info.

Model NO. SRSF1100 Automation Automatic Computerized Computerized Certification CE, ISO9001:2008, SGS/BV Size 1700*2500*2000mm Transport Package Wooden Package/Film Package/Steel Frames Package/C Specification CE/ISO9001/SGS Trademark SOYU Origin China HS Code 84778000 Production Capacity 1000sets/Year

Product Description

Plastic Bags Shredder Film Shredder


This machine specially for waste PP / PE film, snake woven bags, tons of bags, waste paper and design, production can be according to the size of the models to 500-6000KG per hour, material size is about 40-100MM.
Plastic Bags Shredder Film Shredder

Main Features

characteristic:

Feeding mouth large, easy to feed;

Automatic continuous crushing, high yield;

The surface hardening treatment can be used to prolong the service life of the cutter roller surface;

Blade standardized design, so that the blade replacement fast and convenient, the use of cost reduction;

The screen size of a standard design, optional, easy to change.


Plastic Bags Shredder Film Shredder
Plastic Bags Shredder Film Shredder
Plastic Bags Shredder Film Shredder
Plastic Bags Shredder Film Shredder
Plastic Bags Shredder Film ShredderPlastic Bags Shredder Film ShredderPlastic Bags Shredder Film ShredderPlastic Bags Shredder Film Shredder
ModelSR600SR750SR900SR1100
Main shaft speed(rpm)73737373
Ram travel(mm)500820820820
Rotor diameter(mm)Φ220Φ400Φ400Φ400
Number of rotor blades(pcs)23445266
Number of fixed blades(pcs)4668
Discharge height(mm)500610610610
Screen holes diameter(mm)40404040
Motor power(kw)18.5374555~75
Hydraulic power(kw)1.52.22.25.5
Cutting chamber dimensions(mm)540x600830x708830x840830x1071
Overall dimensions(LxWxH)(mm)1800x1350x17002810x2000x21152810x2100x21152810x2650x2115
Weight(kg)Approx 1600Approx 4460Approx 4560Approx 5464
ModelSR1400SR1600SR2100SR2500
Main shaft speed(rpm)73737373
Ram travel(mm)820100010001200
Rotor diameter(mm)Φ400Φ480Φ480Φ660
Number of rotor blades(pcs)8094122150
Number of fixed blades(pcs)10121620
Discharge height(mm)610950950950
Screen holes diameter(mm)40404040
Motor power(kw)75~902x55~2x752x75~2x902x90~2x110
Hydraulic power(kw)5.57.57.511
Cutting chamber dimensions(mm)830x13021000x15331000x19951200x2457
Overall dimensions(LxWxH)(mm)2810x2890x21153475x4100x27003475x4900x27003475x5400x2700
Weight(kg)Approx 6200Approx 10800Approx 13000Approx 16000

Plastic Bags Shredder Film ShredderPlastic Bags Shredder Film Shredder
Plastic Bags Shredder Film Shredder
