Hydraulic Dosing Pump Diaphragm Pump Pressure Washer Pump Water Pump

• Motor：380V 50Hz
• Accuracy：1%

=== Base Info ===

• Model NO.：JYM25
• Transport Package：Wooden Box
• Specification：20000L,H
• Trademark：AILIPU
• Origin：Zhejiang, China
• HS Code：8413502090
• Production Capacity：1000 Sets,Year
• Package size per unit product：120.00cm * 110.00cm * 98.00cm
• Gross weight per unit product：600.000kg

=== Description ===

Basic Info.

Model NO. JYM25 Transport Package Wooden Box Specification 20000L/H Trademark AILIPU Origin Zhejiang, China HS Code 8413502090 Production Capacity 1000 Sets/Year

Packaging & Delivery

Package size per unit product 120.00cm * 110.00cm * 98.00cm Gross weight per unit product 600.000kg

Product Description

Multiple repurchase Spot Supply Industry leading Hydraulic Dosing Metering Pump with Factory Price

Feature

* No dynamic seal, no leakage and easy maintenance

* The working pressure can be up to 80 MPa; the measurement accuracy can be up to +/- 1%; the capacity range of the simplex pump: 0.2L/H - 12000L/H

* The control of the capacity flow is by adjusting of the length of the stroke and the frequency conversion; meanwhile, the remote automatic control can be available when there is the stroke controller or the frequency changer installed.

* The working temperature of the medium should neither exceed 200ºC nor below -30ºC; otherwise it wil influence the life of the diaphragm

* The new three-valve structure and the application of limit oil compensating mechanism not only ensure the fullness of hydraulic oil in the hydraulic working chamber but also avoid filling oil excessively and prevent hydraulic shock so that make the both sides of the diaphragm have balanced force and increase the working life of the diaphragm to more than 8000H.



Application

It can be applied in a wide range from the general water of normal temperature to some liquid which are strong corrosive, volatile, vrystalized, combustible, and explosive, extremely toxic, foul-smelling, moderately viscous, radioactive and other valuable liquid. Meanwhile, it can also transfer some suspending liquid. In order to prevent the accidents caused by the mix of the media and hydraulic oil, or in terms of some liquid which are combustible, explosive, toxic and valuable, the double diaphragm hydraulic metering pumps with the alarm functions for the repture of diaphragms can be applied.

Title goes here.

Main Specification
** The capacity up to 1000 LPH
** The maximum pressure up to 250 bar
** Measuring accuracy reaches to -/+1%
** Temperatures of liquid shall be between -30degree to 100 degreee
** Max.Suct: 5m
Control
** Manual adjustment of the stroke
**Digital controller(accpets 4~20mA singal to adjust the motor speed to control the output)

Zhejiang Ailipu Technology Co., Ltd was founded in 1997, the registered capital is 51.31 Million RMB, it is a high-tech enterprise which is an integration of design, research & development, production and marketing. Ailipu specialized in automatic dosing pump,complete set of dosing skid equipment, steam & water sampling analysis system, control software of skid equipment and generator installation etc...

In 2014, and the wholly owned subsidiary of Zhejiang Ailipu Engineering Control Technology Co. Ltd. (Registered place: Binjiang District, Hangzhou) was founded in the same year; and to improve the core competitiveness of enterprises, the company established Zhejiang Ailipu Qingyan Exhaust emission purification Co., Ltd. in 2015 together with Japan ACR, Tsinghua University.

 At present, the company is the largest enterprise manufacturing automatic metering pump, complete sets of dosing device and fluid quantitative dosing and proportion dosing, but also the first listed company in the metering pump industry.As a trust worthy China Supplier,we have exported our products to lots of countries,and we sincerely hope to cooperate with more friends in the world.
