0.5gallon 2liter Double Station Single Die-Head Triple Layer with View Stripe Blow Molding ...

=== Base Info ===

=== Description ===

Basic Info.

Model NO. TK-2D-1-3P-T Certification CE, ISO9001:2008, UL After-sales Service One Year Max. Volume 1 Litre Station Double Die Head Double Screw Diameter φ60mm Screw L/D Ratio 25:1 Output of HDPE 60kg Extruder Driving Power 15kw Oil Pump Motor Power 5.5kw Claming Force 45kn Platen Opening Stroke 138~368mm Platen Size 280*320mm Air Pressure 0.8MPa Dimension 3600*2260*2200mm Weight 5.5ton Transport Package Wooden Case, PE Film Specification 17CBM Trademark OTO Origin China HS Code 847740 Production Capacity 170 Sets/Year

Product Description

Automatic Double Station Single Die-head Triple Layers With View Striple Extrusion Blow molding machine For 700ml 800ml 900ml 1 Liter 2 liter 0.5gallon 0.25gallon Bottle with conveyor, leak testing, in-mold labeling machine and automatic film packing machine for optional
