- Process:Mild Processing
- Power Source:Electric
- Certification:ISO9001
- Automatic Grade:Automatic
- Application:Milk, Cheese
- Customized:Customized
=== Base Info ===
- Model NO.:KQ
- Name:Stainless Steel Milk Cooling Chilling Heating Stor
- Milk Chilled Tank:500L to 10000L
- Refrigerant:R404 , R22
- Milk Tankapplication:Cooling and Storage Fresh Milk
- Milk Transportation Tank:Also Provided
- Milk Cooling Tank Inside and Outside:Mirror Polished
- Tank Material:Stainless Steel 304 , 316
- Mixer Speed:36rpm
- CIP Cleaning Ball:Provided
- Delivery:10 Days
- Surface Treatment:Inside Mirror and Outside Polished
- Packing:Wooden Box
- Warranty:One Years .
- MOQ:1 Set
- Motor Brand:Siemens ,ABB,China Brand
- Transport Package:Wooden Box
- Specification:SANITARY, FOOD GRADE
- Trademark:KAIQUAN
- Origin:Shanghai, China
- HS Code:8479820090
- Production Capacity:1000 to 10000L
=== Description ===
Basic Info.
Model NO.
KQ
Name
Stainless Steel Milk Cooling Chilling Heating Stor
Milk Chilled Tank
500L to 10000L
Refrigerant
R404 / R22
Milk Tankapplication
Cooling and Storage Fresh Milk
Milk Transportation Tank
Also Provided
Milk Cooling Tank Inside and Outside
Mirror Polished
Tank Material
Stainless Steel 304 / 316
Mixer Speed
36rpm
CIP Cleaning Ball
Provided
Delivery
10 Days
Surface Treatment
Inside Mirror and Outside Polished
Packing
Wooden Box
Warranty
One Years .
MOQ
1 Set
Motor Brand
Siemens /ABB/China Brand
Transport Package
Wooden Box
Specification
SANITARY, FOOD GRADE
Trademark
KAIQUAN
Origin
Shanghai, China
HS Code
8479820090
Production Capacity
1000 to 10000L
Product Description
Stainless Steel Milk Cooling Chilling Heating Storage Tank Price
Type | KQ-1T Vertical type | KQ-2T Laying type | KQ-3T Laying type | KQ-5T Laying type | KQ-6T Laying type | KQ-8T Laying type | KQ-10T Laying type |
Capacity( L) | 1000 | 2000 | 3000 | 5000 | 6000 | 8000 | 10000L |
Refrigerating Output (W) | 9000 | 15000 | 22000 | 37000 | 38000 | 55000 | 74000 |
Refrigerating Fluid(R) | R404/R22 | R404/R22 | R404/R22 | R404/R22 | R404/R22 | R404/R22 | R404/R22 |
Insulating Property | ≤ 1C/4h | ≤1C/4h | ≤1 C /5h | ≤1 C /5h | ≤1 C /5h | ≤1 C /5h | ≤1 C /6h |
Agitator Speed | 36r/min | 36r/min | 36r/min | 36r/min | 36r/min | 36r/min | 36r/min |
Power (Kw) | 3.8 | 5.9 | 7.5 | 10.5 | 11 | 13 | 19.2 |
Voltage | 380V/50Hz,3phases | 380V/50Hz,3phases | 380V/50Hz,3phases | 380V/50Hz, 3phases | 380V/50Hz, 3phases | 380V/50Hz, 3phases | 380V/50Hz, 3phases |
Dimension(mm) | 1800*1200*1500 | 3400*1550*1750 | 3600*1700*1900 | 3900*2050*2150 | 4500*2050*2150 | 6300*2050*2250 | 8000 * 2100 * 2400 |
Weight(Approximately) | 0.6T | 0.75T | 0.9T | 1.1T | 1.3T | 1.8T |
Milk Chilling Tank, You Can Buy Various High Quality Milk Chilling TankProducts from Adopting internationally-advanced technology of the 1900's it cools by circular and vertical wall. The fully automatic control system makes whole process of observation available. The cooled raw milk can reach rapidly needed temperature of 4~5 and keeps constant, which can prevent the generation of bacteria and make raw milk as Agrade cream.
The adopted imported compressor features high performance, energy saving, full seal and protection system that prevents damage due to overload. Also fitted are high / low liquid level control system and automatic cyclespray and agitating device.
Stainless Steel Milk Cooling Chilling Heating Storage Tank Price .
