Diamond Tuck Point Saw Blade with Fast Speed and Smooth Cutting Ability

• Blade Type：Normal,Silent Blade
• Manufacturing Process：Sintered,Electroplate,Laser Welded
• Application：Granite, Basalt,Marble,Concrete etc.
• Segment Material：Diamond Powder, Cobalt, Metal
• Working Condition：Wet,Dry Cut
• Segment Type & Shape：Normal, Turbo; Sandwich, Groove, etc

=== Base Info ===

• Model NO.：HZ-195
• Welding Method：High Frequency Welding,Laser Weld
• Perfromance Comparison：Sharp Diamond Blade, Wearable Diamond Blade
• Type：Power Tool Parts
• Outer Diamond：80mm-350mm
• Inner/Bore Diamond：25.4mm,22.23mm,20mm,16mm
• Segment Height：8,10,12mm
• Thickness：1.7mm,1.8mm,2.0mm,2.2mm
• Transport Package：Carton and Wooden Box
• Specification：4′′-9′′(105mm-230mm)
• Trademark：Huazuan or OEM
• Origin：Quanzhou, Fujian
• HS Code：82023910
• Production Capacity：50000PCS,Month

=== Description ===

Diameter

Bore

Segment

Segment

mm

inch

Size(mm/inch)

Thickness(mm)

Height(mm)

105

4"

20/0.787"

1.8

8/10/12

110

4.3"

20/0.787"

1.8

8/10/12

115

4.5"

22.23/0.875"

1.8

8/10/12

125

5"

22.23/0.875"

2.0

8/10/12

150

6"

22.23/0.875"

2.2

8/10/12

180

7"

22.23/0.875"

2.4

8/10/12

200

8"

22.23/0.875"

2.4

8/10/12

230

9"

22.23/0.875"

2.6

8/10/12

250

10"

22.23/0.875"

2.8

8/10/12

 Other specifications are available upon request. Product Image:1.Segmented Saw Blade:
2.Turbo Saw Blade:

3.Tuck Point Blade:

4.Dry Cutting Blade With Protection Teeth

Attention when use:
1. Before saw blade installed, pollutions adhering between saw blade and flange shall be removed,
  when installing saw blade, the marked direction shall be kept consistent with the rotating
  direction of electric tools, and flange shall be fastened by spanner attached to electric tools.
2. Do not use any saw blade that has been deformed for being pressed of crashed.
3. When operating, operator must wear safety helmet, safety footwear and goggles,
   protective glove,additionally, if necessary operator must use earplug, mask and so on.

4. Electric tools shall have protective cover.
