Spc Resilient Flooring Eir on-Line Embossing Extrusion Production Line

Forsun Ultra-hard Material Industry Co., Ltd. / 2022-07-04

Spc Resilient Flooring Eir on-Line Embossing Extrusion Production Line

=== Base Info ===

=== Description ===

Basic Info.

Model NO. SJSZ110/220 Assembly Structure Integral Type Extruder Screw Twin-Screw Engagement System Full Intermeshing Screw Channel Structure Deep Screw Exhaust Don′t Exhaust Automation Automatic Computerized Computerized Voltage 220-415V / 50-60Hz 3 Phase Power 485-750kw Per Line Production Line Layout 50m (L) * 5m (W) * 8m (H) Calender Five Roller Deliver Time 45 Days Plank Thickness 2-9mm T-Die 1050/1350 Online Embossing Better Than 95% Transport Package PE Wrapping Film, Fumigating Wooden Cases. Specification CE, SGS, UL, TUV, CSA, ISO Trademark BOYU Origin Wuxi, Jiangsu, China HS Code 8477209000 Production Capacity 200 Sets Per Year

Product Description

Spc Resilient Flooring EIR on-Line Embossing Extrusion Production Line
SJSZ110/220 Conical Twin-Screw SPC Flooring Production Line


 I. Design parameters

No.Items Description
01Operation conditions380V/3 phases/60Hz. (or customizable as per different country's standard voltage )
02Materials usedPVC powder, calcium carbonate, stabilizer, lubricant, small materials.
Main Material and proportion: PVC: CaCo3 = 1:1 :2~3
03Extrusion rateDaily capacity: 25-32 Tons/ 24 hours
about 3000m2/ day for 4mm finished SPC flooring
04Product specificationsMaximum width is 1050mm, thickness =2-9mm.
Normal finished board width: 980mm
Normal finished board thickness: δ=1.5~4.0mm
05Total power of whole machine lineAbout 700KW (The exact total power may something  floating as per different configuration requirements



II.Equipment List & Quantity

No.Equipment NameQuantityRemark
01Φ110/220 Conical twin-screw extruder1 Set
02Extrusion die1 Set
03Five-roller calender1 Set
04Film unwinding mechanism & magnetic powder controller    2 UnitsFor two working position
05Oil roller heating system (integral)1 Set 4 units
06Cooling bracket1 unit
07Longitudinal edge cutting mechanism1 unit
08Traction machine2 sets
09Length meter1 Set
10Plate shearing machine1 set
11Automatic plate lifting and stacking system1 unit
12Electric control cabinet1 unit
13Cooing water spray tank1 unit
14wear layer pre-heat device1 unit


III.Production Flow

Material mixing → Extruder → Calender→ Cut-to-length →Stacking →UV coating →Saw cutting →
Slick slotting →Backing limitation →QC inspection → Packing
Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder




IV. Machine Line Layout
Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder

V. Advantages of BOYU WPC Production Machine Line

Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder


VI.Services


Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder

 VII. Project Case

Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder
Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder

Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder



VII. Boyu Company Profile   Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder

Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder

Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder

VIII. Patents Certificates

Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder

BoYu On-line EIR Technology - United States Patent


Sjsz110/220 Conical Twin-Screw Lvt/PVC/WPC/Spc Flooring Production Line/Making Machine/Extrusion Line/Extruder

BoYu On-line EIR Technology - Europe & Taiwan Patents
