18L - 30L Plastic Blow Moulding Machine (PXB100dB)

Shandong Fangdi Trade Co., Ltd. / 2022-07-04

18L - 30L Plastic Blow Moulding Machine (PXB100dB)

=== Base Info ===

=== Description ===

Basic Info.

Model NO. PXB100DB Bottom Blowing Available Material PP, PE, ABS... Total Weight 23t Output(Dry Cycle) 650*2 PC/Hr Die Head Option Accumulator Head Transparent Line Available Production Usage Toys, Bottle, Small Auto Parts, etc Multi-Layer Available Accumulator Capacity 5L Screw Diameter 100mm Transport Package Film Packing with Wooden Bottom Specification Max capacity 30L Trademark Puxin Origin Jiangsu HS Code 847730100

Product Description

PXB100DB
20L-30L Double Station Blow Molding Machine

- Fixed Opening-Closing Clamping with 5L Accumulator Head Capacity
- Perfect Usage for production of Big toys, auto parts, Jerry Can, sprayer and so on.
- Hydraulic Servo System control with quick action speed.
- High capacity amount with energy saving.

Configuration List
PLCMITSUBISHIJapan
Touch ScreenHITECHTaiwan
InverterMITSUBISHIJapan
Power SupplyMEAN WELLTaiwan
RelayOMRONJapan
Hydraulic ValvesYUKENJapan
Hydraulic PumpYUKENJapan
ContactorsLS(LG)Korea
Solid relayFOTEKJapan
BreakerLS(LG)Korea
Temperature Control ModuleMITSUBISHIJapan
Oil SealingDZTaiwan
Oil TubeLIEBAOTaiwan
TransducerGEFRANItaly
Proximity SwitchSONONChina
MotorSIEMENSChina
Air ValveFESTOGermany
Parison ControllerMoogJapan
Servo ValveMoogJapan


18L - 30L Plastic Blow Moulding Machine (PXB100dB)
18L - 30L Plastic Blow Moulding Machine (PXB100dB)

18L - 30L Plastic Blow Moulding Machine (PXB100dB)

Parameters:

Material PE,PP,ABS...
 Max container capacityL30
 Output(dry cycle)pc/hr650×2
 Machine dimension(L×W×H)M6.4×6.2×4
 Machine weightT23
 Clamping Unit
 Clamping forcekn200
Mold platen size(W×H)mm830×800
 Platen opening strokemm350-850
 Platen moving strokemm500
Max mold size(W×H)mm590×700
 Mold thicknessmm360-420
 Power
 Servo oil pump motor powerKW13
 Servo pump displacementL/MIN80
 Blow pressureMPA0.8
 Air consumptionM3/MIN0.7
 Cooling water pressurempa0.3
 Water consumptionL/min70
 Average energy consumptionKW52-60
 Extruder unit
 Screw diametermm100
 Screw L/D ratioL/D24
HDPE Melting capacit for HDPEkg/hr160
 Number of heating zonezone5
 Screw heating powerkw28
 Screw fan powerKW0.5
 Extruder motor powerkw55
 Die head
 Number of heating zone for single die headzone4
 Heating power for single die headkw19
 Max die-pin diametermm250
 Accumulator capacityL5
(HDPE) Accumulator weight(HDPE)KG3.75

Delivery Time:
- No later than 60 days after receipt of the deposit

Training:
- We provide training service for two or three operating men for free (but the cost for trainer's board and lodging is not included).

Installation:
- The supplier will send one specialist to test run the machine until it is running in normal state.

Guarantee:
- Our guarantee is valid for a period of 12 months. If the malfunction caused of the machine's self quality, we will troubleshoot it for free.

Auxiliary Equipments:
- Auxiliary equipments and moulds for production line are available and optional, please kindly ask for quotation.
