100L Gas Heating Jacketed Kettle with Stirrer

• Type：Cooking and Mixing
• Voltage：Can Be Customized
• Power：1.1KW
• Customized：Customized
• Cooking Kettle Capacity：50liter to 600L Customized
• Cooking Pot Structure：Double Layer Made of Stainless Steel

=== Base Info ===

• Model NO.：RG-100
• Agitator：with , Without Agitator, Customized
• Cooking Method：Nature Gas , LGP
• Way of Discharge：Drainage From Bottom , Tiltable
• Construction Material：Ss304 , Ss316L
• Certificate：CE
• Transport Package：Wooden Case
• Origin：Wenzhou China

=== Description ===

Basic Info.

Model NO. RG-100 Agitator with / Without Agitator, Customized Cooking Method Nature Gas / LGP Way of Discharge Drainage From Bottom / Tiltable Construction Material Ss304 / Ss316L Certificate CE Transport Package Wooden Case Origin Wenzhou China

Product Description

Gas Heating Jacketed Kettle With Stirrer
1. Cooking kettle made of stainless steel
2. Jacketed pot with customized cooking capacity
3. Gas heating, nature gas or LGP
4. Automatic control temperature and gas

Jacketed kettle / jacketed pot / cooking kettle
Jacketed kettle is a kind of cooking and mixing device used in dairy proessing and beverage production.
You can produce tomato paste, puree, milk, and many other products by jacketed cooking kettle.
Also, you can make soup by our cooking kettles or cooking pan.
Gas heating jacketed kettle with stirrer (At the bottom of the picture)

Jacketed kettles can be heated by gas. Wenzhou wanyuan food machinery produce gas jacketed kettle in different capacity. We have nature gas heating type cooking kettle, also we produce LGP heating cooking vat or kettle according to customer request.

Gas heating jacketed kettle can be tilting type, or tri-leg mounted. There are not too much different between tri-leg mounted gas cooking kettle and tilting jacketed kettle, the only difference is: They use different kind of drainage method.
Tilting jacketed kettle use gear device to turn the jacketed pot over when discharge while tri-leg jacketed kettle <or vertical jacketed kettle> equipped with a drainage pipe at the jacketed pot <jacketed pan or jacketed vat> bottom.

Gas heating jacketed kettle with stirrer
Most of the gas jacketed kettle are manual control. You need to turn on the gas when start cooking and after cooking you need to turn off the gas by hand. Have you every seen any gas cooking kettle which can turn on and turn off the gas automaticly rather than by hand?
Our cooking kettle can do this! Our gas cooking kettle which produced by wenzhou longwan wanyuan food machinery can turn on and turn off the gas automatically!
Want to know more about our automatic control gas cooking kettle?
Please send us your detail reqeust.

Here below is our gas heating jacketed kettle specification

Specification for gas heating jacketed kettle

Model	Heating Area (m²)	Conduction Oil (kg)	Blending Rate (r/min)	Boiling Time (min)
RG50	0.45	20	35	10~15
RG100	0.58	30	35	10~15
RG150	0.88	45	35	20~30
RG200	1.13	55	35	20~30
RG300	1.43	65	35	20~30
RG400	1.75	75	35	20~30
RG500	2.00	120	35	20~35
RG600	2.30	160	35	20~35
