16mm Drip Irrigation Tape Making Machine 0.15mm-0.6mm 30cm Dripper Distance

=== Base Info ===

=== Description ===

Basic Info.

Model NO. drip irrigation tape machine Engagement System Full Intermeshing Screw Channel Structure Non Deep Screw Exhaust Don′t Exhaust Automation Non-Automatic Computerized Computerized Pipe Thickness 0.15mm-0.6mm Pipe Diameter 16mm,17mm,20mm,22mm Control System Siemens PLC Control Electrics Componets Schneider,Omron Motor Siemens Inveter ABB Brand Dripper Identifying Speed 2500PCS/Min Line Speed 180m/Min, 250m/Min Bearings SKF, NSK Delivery Time 60 Days Container 1X40 Feet Container Transport Package 1X40gp Container Specification 180m/min line speed Trademark KAIDE Origin China HS Code 8477800000 Production Capacity 200 Sets Per Year

Product Description

This flat drip irrigation tape production line is further developed and manufactured, optimizing all the technology of our thousands of high speed & composite pipe production line, absorbing the advanced technology of world class level equipment. It is the leader with the highest speed,fully automation, and outstanding stability.


Tehnical Data

Model	Extruder	Production Speed	Dripper identifying Speed	Tape thickness Range	Punching Speed	Nominal Power
KDPD-III	SJ-60/36	250m/min	2000pcs/min	0.15-0.6mm	≤1800pcs/min	118KW
KDPD-II	SJ-60/36	180m/min	1100pcs/min	0.15-0.6mm	≤700pcs/min	93KW
KDPD-I	SJ-60/36	80m/min	1100pcs/min	0.6-1.2mm	≤400pcs/min	98KW

Features of Flat Drip Irrigation Tape Machine
 (1) HIGH SPEED: We are the highest speed production line in China, the stable production speed 150m/min, the maximum speed:180m/min.
 (2) EASY TO OPERATE: Use the most advanced Simens PLC control system,which can achieve the synchronous control of the the whole line; Fully automatically pipe coiling machine, automatic to change the coil.

 (3) STABLE PRODUCTION:Adopt the world famous brand, such as ABB inverter, Schneilder Electric apparatus, Simens servo motor and PLC.We have more than 20 years experience, each parts of the line are manufacture by ourselves,to be sure of the precision and good quality control.
 (4) HIGH PRECISION :Punching unit adopts visual imaging PLC monitoring system, to make sure the high speed punching precision.
 (5) SAVE COST :High speed improve the production efficiency; automatically function save the human being cost; Thinner Pipe Thickness:0.15mm, can save raw materials cost.
 (6) GOOD APPERANCE:  With Brushed Stainless Steel Vacuum tank & cooling tank, not rustiness, good looks.



(1) Drip irrigation tape is the core of drip irrigation system. It is suitable for planting crops in fields, greenhouses and greenhouses. It can save water and fertilizer and improve economic benefits.
(2) At present, drip irrigation is the most commonly used water-saving irrigation method in arid and water shortage areas. Drip irrigation technology can make water utilization rate reach 95%.
(3) Drip irrigation belt is widely used in the places lack of water. Water saving and grain increasing is an important measure to improve the yield of food crops, and drip irrigation technology plays an important role in food production.
(4) The working principle of drip irrigation technology is to use the low-pressure pipeline system to transport water directly to the field, and then through the emitter, orifice or drip irrigation belt installed on the capillary, the water drops evenly and slowly into the soil near the crop root zone, so that the soil in the most developed area of the crop root system often maintains the appropriate humidity and makes the soil water, fertilizer, gas, heat and microorganism live In order to create favorable conditions for high and stable yield of crops.
(5) The water for drip irrigation is stabilized, filtered and fertilized by the first filtration system, then passed through the main pipe and branch pipe, and finally dropped to the plant root through the drip irrigation belt. In a word, drip irrigation is suitable for crops in water shortage area.

Kaide Plastics Machinery Co.,ltd has more than 20 years' experience of plastics pipe extrusion machinery, especially for high speed pipe production line and composite pipe production line.
Our main products are:
Flat drip irrigation tape line,Round Drip Irrigation pipe machine
PPR/PERT/HDPE pipe line,Glassfiber PPR Pipe Line,PPR-AL-PPR pipe line,PEX-AL-PEX pipe machine,PERT-AL-PERT pipe machine,Mulilayer Al-plastic pipe production line,Multi-layer EVOH/PERT/PEXA/PEXB pipe line,PB pipe production line,PPR pipe machine, Medical catheter line,etc .
(1) The machinery have been exported to many countries, such as: Russia, USA, Korea, Algeria, Egypt, Iran, Japan, Kyrghyzstan, Cyprus, Morocco, Ukraine, Mexico, Estonia, Saudi arabia, Uzbekistan, etc,which has gained high reputation from the customers.
(2)Professional R&D team,which are continuously concentrating on optimizing of our technology to keep the leading position. Several technologies have obtained nationalinvention patent & utility model patent;The Whole process of machine manufacturing is under good quality control.
(3)From raw material purchasing, to components manufacturing, thento test running of the line, each process we have strict quality requst, to ensure that a high quality product will be delivered to the customer; We cooperate with well-known enterprises for some mechanical parts, such as: ABB, Siemens, Schneider,Autonics, SMC,Delta,ORMON,Eurotherm,PAKER, etc.
(4)We are located in Weifang, Shangdong Province, near to Qingdao city,warmly welcome to visit our factory, here is  two hours  away from Shanghai, one hours away from Beijing, three hours away from Guangzhou.









For more information, please contact us right now to know more !
