- Certification:CE, MET, CSA, UL, SA8000, ISO9001
- Power Source:Electric
- Process:Frozen and Chilled
- Warranty:1 Year
- After-sales Service:Online Support,Visit Client′s Plant Site
- Automatic Grade:Automatic
=== Base Info ===
- Jacket Type:Dimple Jacket
- Control:PLC Automatic
- Keywords:Milk Cooling Tank,Milk Cooler,Milk Storage Tank,Da
- Output:Low Temperature Fresh Milk,Juice,Dairy
- Feeding:Milk,Juice ,Dairy
- Function:Cool and Storage for Fresh Milk, Juice
- After-Sales Service Provided:Online Support,Visit Client′s Plant Site
- Core Components:Jacket Storage Tank with The Compressor
- Cooling Method:Compressor Chiller
- OEM:Parameter Customization
- Material:304,316L Stainless Steel
- Applicable Industries:Fresh Milk, Juice, Beverage
- Customized:Customized
- Application:Milk, Yogurt, Milk Powder, Cheese
- Model NO.:ZLG
- Tank Layer:Double Jacket Type
- Transport Package:Export Standard Package
- Specification:20L-10000L
- Trademark:JOSTON
- Origin:Wenzhou
- HS Code:8479820090
- Production Capacity:30 Sets,Month
=== Description ===
Basic Info.
Model NO.
ZLG
Application
Milk, Yogurt, Milk Powder, Cheese
Customized
Customized
Applicable Industries
Fresh Milk, Juice, Beverage
Material
304/316L Stainless Steel
OEM
Parameter Customization
Cooling Method
Compressor Chiller
Core Components
Jacket Storage Tank with The Compressor
After-Sales Service Provided
Online Support/Visit Client′s Plant Site
Function
Cool and Storage for Fresh Milk, Juice
Feeding
Milk/Juice /Dairy
Output
Low Temperature Fresh Milk/Juice/Dairy
Keywords
Milk Cooling Tank/Milk Cooler/Milk Storage Tank/Da
Control
PLC Automatic
Jacket Type
Dimple Jacket
Tank Layer
Double Jacket Type
Transport Package
Export Standard Package
Specification
20L-10000L
Trademark
JOSTON
Origin
Wenzhou
HS Code
8479820090
Production Capacity
30 Sets/Month
Product Description
Stainless Steel Dairy Milk Juice Direct Cooling Tank Vessel With Compressor System constructure :
Stainless Steel Dairy Milk Juice Direct Cooling Tank Vessel With Compressor System consists of milk tank, agitator mixer, compressor unit and electrical control.The milk tank body is made of stainless steel, which is round and straight wall with large area cooling. Through the full-automatic control system, one-step observation and operation can quickly reduce the raw milk to the required temperature and maintain the constant temperature. Prevent bacteria from propagating.Polyurethane foaming process is adopted for the thermal insulation layer, with good thermal insulation performance.Stainless Steel Dairy Milk Juice Direct Cooling Tank Vessel With Compressor System temperature can keep as 4 degree for long time.Stainless Steel Dairy Milk Juice Direct Cooling Tank Vessel With Compressor System is Mainly used for cool and storage for fresh milk, also can be used to keep other liquid product .Stainless Steel Dairy Milk Juice Direct Cooling Tank Vessel With Compressor System Features:* working capacity from 50L to 20000L* Material: Stainless steel 304( SS316L is Optional)* Heat preservation material: PUF -thickness is 50mm* Refrigeration unit brand: MANEUROP compressor* Refrigerants is R22 ( R404A )* control system (PLC/HMI is optional)Accessories: CIP clean ball/ manhole/vent filter/Mixer deviceStainless Steel Dairy Milk Juice Direct Cooling Tank Vessel With Compressor System Technology Data specification:Capacity | Refrigerating Capacity (W) | Thermal insulation | Rotating speed for agitator | Voltage | Compressor Power (KW) | Compressor brand | Compressor model |
500L | 8020 | 18h/≤2ºC | 36rpm | 2×220V | 2.2 | Danfoss Maneurope | MT-36 |
1000L | 15500 | 18h/≤2ºC | 36rpm | 3×380V | 3.75 | Danfoss Maneurope | MT-50 |
2000L | 17700 | 18h/≤2ºC | 36rpm | 3×380V | 5.5 | Danfoss Maneurope | MT-80 |
3000L | 17700 | 18h/≤2ºC | 36rpm | 3×380V | 5.5 | Danfoss Maneurope | MT-80 |
5000L | 31000 | 18h/≤1.5ºC | 36rpm | 3×380V 50HZ | 5.5x2 | Danfoss Maneurope | MT-80x2 |
SERVICEWe have established some overseas agent office to make the after-sales service already ,so it can will be service client in fast response .also in our headquarter service team ,there is a expert team which can support client in 7*24 hours .1. Customer inquiry and consultation (URS documents)2. Confirmation of treatment plan (DQ documents &PID Drawing)3.Quotation offer with the technology document (Quotation PI )4.Engineering and Manufacturing (Production &Quality inspection )5. Product inspection (FAT documents)6. Delivery arrangement and loading work (full set Shipment documents)7. After-sales service (OQ,PQ ,SAT documents)FAQ1.What about your factory?Our factory is located in Wenzhou city ,Zhejiang Province and have more than 15 years experience on machinery making.2.How will your company control the equipment quality ?We have a qualified expert team ,we will inspect every production proceed .also Machines will be tested in our plant before shipment .3.How long the warranty will be?We provide 1 year warranty for the machine running ,but we will afford whole -life service for the machine .4.Which kind payment do your company do now ?We accept Western Union, T/T ,D/P,D/C and irrevocable L/C payable etc.5.Can we become your distributor in our country?Yes, we very welcome you! More details will be discussed if you are interested in being our agent.6.Why we choose "JOSTON "?1. We enhance the reliability of product's quality and working life . 2. We decrease the consumption cost of the product in the ruuning. 3. We improve research personnel's ability to deliver a creative design; 4. We use leading technologies in our product development and innovation, and thereby increase the competitive advantage of products.7.Do you supply installation equipment in oversea?Yes, if need, we can send our engineer to your plant to help you do installation and commission.8.How can we know the order production status ?We will arrange the person to take photo or video during manufacturing in every week to make you to know the production status.When goods are finished,we will take detailed photos or video for your checking ,after approve ,then we will arrange shipment .also you can arrange FAT in our plant when the goods is ready here9.what is kind service do you offer before making order ?1.according to your company URS ,we will make the design drawing accoridingly.2.after your company approved drawing ,we will make quotation.3. final we make agreement on payment terms ,delivery time ,package ,shipment etc.10.how about your company after-sale serivce ?1. We provide long-term after-sale service. 2. we can do installation and commission for the equipment in your plant if necessary .3. Meanwhile, you can call or e-mail us to consult on any relevant question since we have a special line for after-sale service. Alternatively, you can communicate on-line with us to solve any problem.
