1325 1610 Two Heads Carbon Steel Cutter CO2 Laser Machine for Metal and Non-Metal

• Application：Environmental Equipment, Textile Machinery, Woodwork Industry, Advertising Industry
• Cooling System：Water Cooling
• Technical Class：Pulse Laser
• Applicable Material：Nonmetal
• Structure Type：Desktop
• Laser Classification：CO2

=== Base Info ===

• Model NO.：LT-1610
• Laser Technology：Laser Fusion Cutting
• Working Table：Blade Table
• Laser Type：CO2 Laser Type
• Laser Power：150W
• Working Area：1600*1200mm
• Control System：Ruida Rdc6332m
• Software：Rdworks V8
• Life of Laser Tube：8000-10000hours
• Water Chiller：Cw3000
• Laser Tube Cooling：Water Cooling
• Motor：Stepper Motor
• Driver：Leadshine Driver
• Design Software：Autocad,Coreldraw
• Transport Package：1880*1440*1220mm
• Specification：3.302m3
• Trademark：LINTCNC
• Origin：China
• HS Code：8456110090
• Production Capacity：600sets,Year

=== Description ===

Technical parameters of 1610 co2 laser cutting engraving machine with two laser heads for metal&non-metal



DescriptionLT-1610 laser machineLaser tube coolingWater coolingWorking area1600*1000mmDriversLeadshine driversM883Laser power180w & 90wMotorsStepper motorsWorking tableblade tableTransmission systemTaiwan Hiwin square railsLaser typeCo2 laser tubeControl systemRuida RDC6332MLife of laser tube8000-10000 hoursSoftwareRdworks V8Engraving speed0-1000mm/sDesign softwareCorelDraw/AutoCADCutting speed0-700mm/sPicture formatPLT,DXF,BMPCutting ability of different laser power Acrylic(mm)Wood(mm)MDF(mm)60W85480W/90W1287100W15109130W201513150W302020ApplicationApplication materialsCutEngraveAcrylic/Plexiglass/PMMA/Perspex/Organic board/Double color plate√√Wood/Plywood/Veneer/MDF/Blasa wood/Bamboo√√Plastic/PP/PET/PC/PS/PS/PES/PA/Plastic films&foils√√Leather/PU/Shoe materials/Synthetic leather/Genuine leather√√Fabric/Cloth/Textile√√Carpet/MAt/Rug/Wool felt√√Paper/Cardboard/Chipboard/Press board√√Foam&Filter/Mats polyester(PES)/Polyethylene(PE)√√Stone/Ceramic/Granite/Marble/Natural stone/Pebble stone/Slate √Rubber stamps/Natural rubber√√Glass/Pressed glass/Float glass/Crystal glass/Mirror glass √

Machine parts:






Machine Introduction:

 a. Can be installed with laser tube with different laser power, such as 60w, 80w,90w,100w,150w

 b.  Multi-function; engraving and cutting non-metals with high precision

 c.  Laser head, high speed, more precision, it is metal, not consumable

 d.  Fireproof window, more security

 e.  Laser tube is separated with the working table, this makes sure laser tube safety and laser parts clean

 f. Lens and mirrors imported form Singapore with high quality

 g. Stable stepper motor improves the cutting precision and speed

 Applicable Material:

Two laser heads: normal laser head&metal laser head:

-Normal laser head:

For engraving:All non-metals

For cutting:Most non-metals,such as Acrylic,PVC,rubber sheet,palstic,crystal,glass,bamboo,plywood,

oxhorn,figuline,leathe,cloth,etc.

-Metal laser head:

Cutting non-metal and metal(stainless steel,carbon steel)

Samples

More machine models



Our Services
  Warranty and after-sale service:
 1)24 months warranty for the whole machine,10 months for laser tube.
  If there is any quality problem during warranty period,will change the part for you for free.(Except the human damage);Out of warranty period, if there is any problem,you can buy the part easily as we all use parts with famous brand;also you can buy from us and cost price can be promised.

  2)Software manual,machine operation manual,software installation video,machine operation video etc. will be sent for your checking .

  3)24 hours online service from professional engineers.
Packaging & Shipping

 Packing size: 2280*1540*1220mm

 Packing weight: 550kg

 Packing details: One plywood case with water proof materials.
