CO2 Laser Marker 30W 60W 50W on Wood /Paper/Leather

• Laser Visibility：Visible
• Applicable Material：Nonmetal
• Cooling System：Air Cooling
• Technical Class：Pulse Laser
• Laser Wavelength：CO2 Laser
• Laser Classification：CO2 Laser

=== Base Info ===

• Model NO.：HJZ-CDB-04
• Type：CO2 Laser Marking Machine
• Marking Method：Scanning Marking
• Laser Source：Us Synrad
• Engraving Speed：9000mm,S
• Laser Type：CO2 Laser
• Wavelength：10.6um
• Marking Area：110*110mm, 175*175mm, 220*220mm, 300*300mm
• Max Single Pulse Energy：1.0mj
• Laser Beam Quality M2：<1.2
• Application Material：0.1-2mm
• Process Material：Metal and Some Non-Metal
• Cooling Type：Air Cooling
• Marking Speed：1-8000mm,S
• Lifespan：Over 20, 000hours
• Graphic Format：JPG, BMP, Dxf, Plt, Ai, Dst
• Control Software：Ezcad Software
• Marking Depth：0.01-0.08mm
• Transport Package：Standard Plywood Packing for Export
• Specification：1650X1250X1050MM
• Trademark：HZJ
• Origin：Wuhan, China
• HS Code：84561000
• Production Capacity：600sets,Month

=== Description ===

Basic Info.

Model NO. HJZ-CDB-04 Type CO2 Laser Marking Machine Marking Method Scanning Marking Laser Source Us Synrad Engraving Speed 9000mm/S Laser Type CO2 Laser Wavelength 10.6um Marking Area 110*110mm, 175*175mm, 220*220mm, 300*300mm Max Single Pulse Energy 1.0mj Laser Beam Quality M2 <1.2 Application Material 0.1-2mm Process Material Metal and Some Non-Metal Cooling Type Air Cooling Marking Speed 1-8000mm/S Lifespan Over 20, 000hours Graphic Format JPG, BMP, Dxf, Plt, Ai, Dst Control Software Ezcad Software Marking Depth 0.01-0.08mm Transport Package Standard Plywood Packing for Export Specification 1650X1250X1050MM Trademark HZJ Origin Wuhan, China HS Code 84561000 Production Capacity 600sets/Month

Product Description

  CO2 Laser Marking Machine for Expire Date HDPE/Plastic Water Bottle
Contact : Susie Xu




Our Features:
1.United States imported CO2 laser tube,
2.SINO-GALVO galvo head with speed 7000mm,
3.Imported lens made of zinc selenide,
4.Machine warranty for 2 years,
5.Top quality JCZ motherboard and EZCAD control software,
6.Taiwan MeanWell brand power supply,
7.We support DHL / TNT / FEDEX EXPRESS air shipping to door,

Applicable material:
Wood, paper, leather,cloth, plexiglass, epoxy, acrylic, unsaturated polyester resin and other non-metal materials.

Control software:
-EZCAD software( The latest version of EZCAD)
-Easy to use, smooth operation
-Support WIN XP, WIN7, WIN 8, WIN10 (32bit/64bit)
-Support multiple formats AI, PLT, DXF, BMP, DST, DWG, LAS, JPG, DXP,etc.
 techical parameters:

Model	HJZ-CDB-30
Laser source	US SYNRAD
Laser type	Co2 laser
Wavelength	10.6um
Max Single pulse energy	1.0mj
Pulse duration	90-130ns
Laser beam quality M2	<1.2
Marking speed	1-8000mm/s
Frequency	20-60khz
Marking Area	100*100mm-300*300mm (optional)
Marking Depth	0.01-0.08mm
Controller	Computer with marking software
Control program	EZCAD control system  Compatible with win7/8/10
Graphic format supported	JPG,BMP,DXF,PLT,AI,DST
Working voltage	AC220V 50HZ, AC110V 60HZ
Cooling type	Air cooling
Operating parameter	0-40ºC
Warranty	Laser source we warranty for 1 year/the other parts warranty for 2 years
G.W.	90KG
Package(L*W*H)	1090X460X780mm

Packing list:

30W CO2 laser marking machine	1 set
Laser source test report	1 set
CD with EZCAD control program	1 set
Foot switch	1 set
USB flash disk	1 set
Power cord	1 set
Inner hexagon wrench	1 set
Ruler	1 set
