6.5tpd Combined Soybean Oil Press Machine with Oil Filter

• Type：Spiral Oil Press
• Application：All, Edible Oil
• Voltage：380V
• Appearance：Uniaxial
• Press Materials：All Kinds of Seeds and Nuts
• Press Series：Second

=== Base Info ===

• Model NO.：YZLXQ120
• Condition：New
• Customized：Customized
• Power(W)：11kw
• Usage：All Kinds of Oil Seeds
• Automatic Grade：Automatic
• Processing Capacity：6.5ton Per Day
• Factory History：30years Manufactur Experience
• Size：1948*1522*1915
• Weight：1200kgs
• Transport Package：We Use Top Standard Fumigated Wooden Box Packing.
• Specification：ISO, BV, SGS
• Trademark：GUAGNXIN
• Origin：Sichuan, China
• HS Code：84792000
• Production Capacity：400 PCS,Month

=== Description ===
Guangxin  Automatic Combined Oil Press with Air pressure Oil filter seriesModelYZLXQ10(95)YZLXQ10-6/8/9YZLXQ120YZLXQ130YZLXQ140Processing capacity (t/24h )3.5~44.56.589~11Oil content of dry cake(%)≤7.8≤7.8≤7.6≤7.6≤7.6Oil press power(k.w )7.5111515 or 18.518.5 or 22The power for Filtration(k.w)1.51.51.51.51.5Temperature Control power(k.w)≥3.0≥3.0≥3.0≥3.0≥3.0Measurement(LxWxH)1790*1520*19151890*1520*19151948*1522*19151948*15229*19152120*1350*1890Spiral axes rotate speed (r/min)32-4032-4032-4432-4432-44Weight (kg)10231075120014001400


1. Technical features of oil extractor machines
1. Its characterized by advanced design, convenient operation, high output, strong compatibility and high efficiency.
2. It has changed the traditional way of increasing the temperature of squeeze chest, therefore can reduce the working time, and also reduce the waste of power and consumption of machine, otherwise it has lengthened the service life of the machine. If working process was interrupted, the squeeze chest could keep on a certain temperature automatically.


3. It has the applicable main motor and complete precision filtration system. After the oil squeezed from the squeeze chest, the oil will be filtered in the air pressure filter, so the users can get clear oil directly.
2. Suitable oil seeds
Can press different kinds of oil seeds like rapeseeds, cotton seeds, soybean, shelled peanut, flax seeds, sunflower seeds, sesame seeds, corn germ, palm kernel, etc.



3. Quality Standard
Conform to JB/T9793· 1-1999 of The People's Republic of China & ISO9001: 2008.


4. Warranty terms
Free replacement of main body in 12 months from the date of purchasing if ther are quality problem.
5. After-sale service
1. We supply spare parts timely all year around at factory cost.
2. We afford technical solutions for buyers at any time.
