Industrial Frozen Fresh Meat Grinder Mincer

Weifang Yunsheng Group Co., Ltd. / 2022-07-04

Industrial Frozen Fresh Meat Grinder Mincer

  • After-sales Service:Video Support
  • Warranty:1 Year
  • Power Source:Electric
  • Process:Thermal Processing
  • Automatic Grade:Automatic
  • Type:Meat Grinder

=== Base Info ===

  • Model NO.:C160
  • Voltage:380V
  • Customized:Customized
  • Transport Package:Sea
  • Specification:2CMB
  • Trademark:CHENGYE
  • Origin:China
  • HS Code:843850
  • Production Capacity:1000 Sets,Year

=== Description ===

Basic Info.

Model NO. C160 Voltage 380V Customized Customized Transport Package Sea Specification 2CMB Trademark CHENGYE Origin China HS Code 843850 Production Capacity 1000 Sets/Year

Product Description

                                                            C160 Frozen Meat Grinder

Industrial Frozen Fresh Meat Grinder Mincer


1.Feature:
ModelC160G-B
Motor Power18.5Kws
VSD18.5Kws VSD
V/Hz380V 50Hz
Weight560Kgs
Auger SpeedVariable Speed Control
Available Frozen Meat Dimension Max. 50*50*150 mm
Capacity1 - 5T/Hour (Up to different hole size of hole plate and temperature of raw meat)
Dimension1450*1000*1400 mm

2. Material Feature:
  • Main Body: Body shell, hopper and rear door is 3mm SUS304
  • Electrical Box:2mm SUS304,Outlet safety cover is 3mm SUS304.
  • Bottom U shape hopper is 4mm SUS304, front and rear support is 10mm SUS304(Whole welding).
  • Frozen meat auger; frozen meat auger housing; fresh meat auger; fresh meat auger housing; knife housing; clamp; locker cap; spacer ring; guiding shaft housing; flange of rear gear box is SUS304.
  • Internal support parts including 60*30*4 cube tube SUS304.
  • Knife shaft; hole plate and knife is special heat treatment stainless steel.
  • Scored pulley is globe standard B type 4 channel casting iron.
  • C160 meat grinder can mincer for -15 degree meat and fresh meat.
  • C160 can setting by single cut (need spacer ring) or dual cut. (See Below Photo)
  • All contactor is Siemens, all relay is Omron, all button is Germanany brand.
  • Safety device: standard outlet safety cover, upper hopper safety fence, rear door safety device.
Industrial Frozen Fresh Meat Grinder MincerIndustrial Frozen Fresh Meat Grinder MincerIndustrial Frozen Fresh Meat Grinder MincerIndustrial Frozen Fresh Meat Grinder MincerIndustrial Frozen Fresh Meat Grinder MincerIndustrial Frozen Fresh Meat Grinder Mincer
