2000W Fiber CNC Pipe Laser Cutting Machine Metal Tube Mild Steel Tube Laser Cutter Automatic Loading and Unloading system 6m

• After-sales Service：Online Support
• Warranty：1 Year
• Application：Home Appliance, Environmental Equipment, Petroleum Machinery Manufacturing, Agriculture Machinery, Food Machinery, Aerospace Industry, Automotive Industry, Advertising Industry
• Cooling System：Water Cooling
• Technical Class：Continuous Wave Laser
• Applicable Material：Metal

=== Base Info ===

• Model NO.：6020
• Structure Type：Gantry Type
• Laser Classification：Fiber
• Laser Technology：Laser Head
• Laser Cutting Machines Laser Power：1000W,1500W,2kw,3kw
• Working Table：Sawtooth Platform
• Model：1530 Fiber Laser Cutting Machine
• Laser Wave Length：1064nm
• Maximum Idle Running Speed：1200mm,S
• Position Accuracy：0.05mm,M
• Position Speed：20m,Min
• Minimum Line Width：0.02mm
• Cutting Thickness：<6mm
• Position Type：Red DOT
• Power Consumption：<12kw
• Working Voltage：380V,50Hz
• Auxiliary Gas：Oxygen,Nitrogen,Air
• Working Life of Fiber Module：More Than 100000 Hours
• Fiber Laser Cutting Head：Lasermech Made in USA
• Transport Package：Wooden Box
• Specification：1500mm*3000mm
• Trademark：Dxtech
• Origin：Shandong
• HS Code：8461500090
• Production Capacity：300 Per Month

=== Description ===

Basic Info.

Model NO. 6020 Structure Type Gantry Type Laser Classification Fiber Laser Technology Laser Head Laser Cutting Machines Laser Power 1000W,1500W,2kw,3kw Working Table Sawtooth Platform Model 1530 Fiber Laser Cutting Machine Laser Wave Length 1064nm Maximum Idle Running Speed 1200mm/S Position Accuracy 0.05mm/M Position Speed 20m/Min Minimum Line Width 0.02mm Cutting Thickness <6mm Position Type Red DOT Power Consumption <12kw Working Voltage 380V/50Hz Auxiliary Gas Oxygen,Nitrogen,Air Working Life of Fiber Module More Than 100000 Hours Fiber Laser Cutting Head Lasermech Made in USA Transport Package Wooden Box Specification 1500mm*3000mm Trademark Dxtech Origin Shandong HS Code 8461500090 Production Capacity 300 Per Month

Product Description

Features
1. With the excellent metal pipe clamping system, the machine can stably deliver metal pipes and manufacture high-quality and
high-precision products. And itcan be equipped with a slag removal device for the inner wall of the pipe.
2. With the world-class Raycus/Max laser source adopted, the machine releases high-quality laser beam and processes materials
precisely. The cutting edge is flat and smooth without any burrs.
3. Manufactured with aerospace aluminum gantry, this machine has high processing precision, good toughness and high processing
speed.
4. The machine can perform various 3D processing effects on metal pipes, such as hole cutting, arc cutting, carving, slotting,
etc. And it can deal with various special-shaped metal tubes, such as rectangular tubes, oval tubes, square tubes, round
tubes, triangular tubes, D-shaped tubes and hexagonal tubes.
