Moog/D661 Series /4186/4187/4931/5611/5625c/6313c/6324/4444c/4577c/4636/4469c/4697c/4651/4303c/4539c/4653/4506c/Pilot-Operated Valve/D661-4069-Moog Servo Valve

• Function：Balance, Pressure Regulating, Reversing, Flow Control
• Installation：Superposition
• Drive：Electric Hydraulic
• Type：Directly Operated Type
• Transport Package：Box
• Specification：STEEL

=== Base Info ===

• Model NO.：D661-4069
• Trademark：MOOG
• Origin：Philippines
• HS Code：8481201000
• Production Capacity：5000 PCS,Year

=== Description ===
SpecificationsHydraulic Data Rated Flow20 to 200 l/min (5.3 to 53 gpm) @ p 35 bar (500 psi) per landMaximum Flow250 l/min (65 gpm) ISO size 05 (second T-port connected)Maximum Operating Pressure350 bar (5,000 psi)Mounting PatternISO 4401 Size 05100% Step Response6.5 to 14 ms @ 210 bar (3,000 psi)Electrical Data Supply Voltage24 VDC (18 to 32 VDC)Rated Signal Options+/-10 V, +/-10 mA, 4-20 mA
