Thick Metal Welder1000W Fiber Laser Welding Machine for Ss CS

• After-sales Service：Free Spare Parts
• Warranty：2 Years
• Application：Electronic Industry, Automotive Industry, Manufacturing Industry
• Technical Class：Continuous Wave Laser
• Control：Manual
• Power Density：Heat Conduct Welding

=== Base Info ===

• Model NO.：LS1LW
• Laser Classification：Optical Fiber Laser
• Type：Portable Welding Machine
• Interface Type：Qbh
• Power Range：1000W-2000W
• Laser Wavelength：1064-1080
• Colimation Length：50
• Focal Length：120,150
• Transport Package：Plywood Box
• Specification：146*77*130cm
• Trademark：Lansen
• Origin：Jinan
• HS Code：8456110090
• Production Capacity：300 Sets,Month

=== Description ===

Basic Info.

Model NO. LS1LW Laser Classification Optical Fiber Laser Type Portable Welding Machine Interface Type Qbh Power Range 1000W-2000W Laser Wavelength 1064-1080 Colimation Length 50 Focal Length 120/150 Transport Package Plywood Box Specification 146*77*130cm Trademark Lansen Origin Jinan HS Code 8456110090 Production Capacity 300 Sets/Month

Product Description

Thick metal welder1000W Fiber Laser Welding machine for SS CS

Equipment description:
 Mainly used for plastic mold of S136, SKD-11, NAK80, 8407, 718, 738, H13, P20, W302, 2344 mold steel, carbon steel, common alloy steel, stainless steel, beryllium copper, copper and extremely hard alloy material, Casting mold, forging die, stamping die, die casting molds. Widely used in mobile phones, digital products, automobiles and motorcycles and other mold manufacturing and molding industry.

Parameters:

Machine model	LS-W1000
Max laser power	1000 watt
Laser source	Raycus
Laser wavelength	1064nm
Max power of single impulse	200J
Pulse width	0.1-25ms
Laser welding method	continuous
Instability of energy	<2%
Beam Divergence	≤8mrad
minimal beam diameter	0.1mm
Adjustable scope of laser spot	0.1~1mm
Welding depth	3~4mm
Continue working time	16hours
Noise	≤30db
Transmission system	Fiber optical transmission system (FOTS)
Fiber optical length	10m standard
Power Consumption	≤7.2KW
Cooling system dimensions	Water cooling
Power required	380V±10%/50Hz
Consumable	Xenon lamp,Filter element,Protective lens,Argon
Working temperature	55°F(13°C)-82°F(28°C)
Working Humidity	5%-75%
Oil mist	≤15mg/m³
