- After-sales Service:Online Service
- Warranty:One Year
- Condition:New
- Customized:Customized
- Voltage:380V,220V,440V,415V
- Composition:Water Treatment Equipment
=== Base Info ===
- Model NO.:KQ
- Processing Material:Natural Ingredients
- Process:Homogenizing and Fining
- Name:Food Sanitary Stainless Steel High Pressure Milk H
- Capacity:500L,H--10000L,H
- Pressure:250bar to 700bar
- Homogenizer Life Time:More Than 10years
- Material:304 , 316
- Homogenizer Spare Parts:Provided
- Packing:Plywood Box
- Homogenizer Electricity:220V,380V,415V,440V
- Certificated:CE
- Delivery:Within 10 Days
- Spare Parts:Available
- Motor Brand:Siemens ,ABB ,China Brand
- Stage:Two Stage
- Plunger:3 Plunger
- Working Pressure:OEM
- Transport Package:Standard Wooden Box
- Specification:Based on special order
- Trademark:KAIQUAN
- Origin:Shanghai, China
- HS Code:847982009
- Production Capacity:100 Units,Month
=== Description ===
Basic Info.
Model NO.
KQ
Processing Material
Natural Ingredients
Process
Homogenizing and Fining
Name
Food Sanitary Stainless Steel High Pressure Milk H
Capacity
500L/H--10000L/H
Pressure
250bar to 700bar
Homogenizer Life Time
More Than 10years
Material
304 / 316
Homogenizer Spare Parts
Provided
Packing
Plywood Box
Homogenizer Electricity
220V,380V,415V,440V
Certificated
CE
Delivery
Within 10 Days
Spare Parts
Available
Motor Brand
Siemens /ABB /China Brand
Stage
Two Stage
Plunger
3 Plunger
Working Pressure
OEM
Transport Package
Standard Wooden Box
Specification
Based on special order
Trademark
KAIQUAN
Origin
Shanghai, China
HS Code
847982009
Production Capacity
100 Units/Month
Product Description
Food Sanitary Stainless Steel High Pressure Milk Homogenizer
Model No. Technical parameter | KQ0.5-25 | KQ1-25 | KQ1.5-25 | KQ2-25 | KQ2.5-25 | GJB3000-25 KQ3-25 | KQ5-25 |
Rated pressure(MPa) | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
Rated flow ( Liters/H ) | 500 | 1000 | 1500 | 2000 | 2500 | 3000 | 5000 |
Medium temperature(C) | ≤85 | ≤85 | ≤85 | ≤85 | ≤85 | ≤85 | ≤85 |
Feeding pipe diameter(mm) | 25 | 25 | 25 | 25 | 25 | 32 | 40 |
Discharge pipe diameter(mm) | 15 | 15 | 20 | 20 | 20 | 20 | 25 |
Power of motor(Kw) | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 45 |
Volt and Electricity Flow | 220V,60HZ,3PH | 380V,50HZ | 380V,50HZ | 380V,50HZ | 220V,60HZ,3PH | 380V,50HZ | 380V,50HZ |
Outline dimension (m) Length * width * height | 1.16×0.9×1.24 | 1.16×0.9×1.24 | 1.16×0.9×1.24 | 1.4×1.1×1.42 | 1.4×1.1×1.42 | 1.4×1.1×1.42 | 2.2×1.45×1.1 |
Weight(Tons) | 0.4 | 0.5 | 1.25 | 1.25 | 1.25 | 1.25 | 1.7 |
High pressure homogenization is a standard industrial process for dairy products, to improve their stability and shelf life
Series is the kind of equipment which can homogenize the liquid material and make it become high-pressure spray. The high pressure homogenizer pump reciprocates the pump position, high press the liquid, fully mixed and refined the material.
The high pressure homogenizer can use to homogenize the dairy product material in high pressure, refine the fat globule, prevent or decrease the stratifying of the liquid material; Make the product much more nicety, to prove the quality of the product.
The high pressure homogenizer pump also the important equipment of the powder manufacture. (Such as pharmaceutical industry, chemical industry, etc. )Food Sanitary High Pressure Milk Homogenizer
Food Sanitary Stainless Steel High Pressure Milk Homogenizer .
