Male O-Ring Boss to Female 37° Jic Swivel Hydraulic Adapters

• Pressure：High Pressure
• Work Temperature：High Temperature
• Thread Type：External Thread
• Installation：Flared Type
• Material：Carbon Steel
• Type：Hydraulic Power Units

=== Base Info ===

• Model NO.：6402-O
• Size : 04,06,08,10,12,16,20,24,32：Surface Treatment: Yellow or White Zinc Plated
• Auxiliary Components：Pipe and Pipe Fittings
• Transport Package：Plastic Bag+Box +Pallet
• Specification：4-32
• Trademark：OEM OR NO BRAND
• Origin：Ningbo, China
• HS Code：73079200
• Production Capacity：500000PCS,Month

=== Description ===

Basic Info.

Model NO. 6402-O Size : 04,06,08,10,12,16,20,24,32 Surface Treatment: Yellow or White Zinc Plated Auxiliary Components Pipe and Pipe Fittings Transport Package Plastic Bag+Box +Pallet Specification 4-32 Trademark OEM OR NO BRAND Origin Ningbo, China HS Code 73079200 Production Capacity 500000PCS/Month

Product Description

Product Name: :6402-O
Product name: SAE Hydraulic fitting/ steel fitting/ hydraulic adapter T TYPE

1. Raw Material: Carbon Steel & Stainless Steel available
2. Standard Plating: Trivalent Zinc Plating ( Cr3 / Chrome Free ), Silver & Yellow
3. Salt Spray Test: > 72 Hours ( If customer have higher requirement, we can also do with 200 Hours )
4. Packing: Products are protected with the plastic caps and then packed in carbon box.
5. OEM Service: Available. Customer only need to provide the product drawing or samples.
6. Sample. Please contact our sales person for the free sample.


Name	JIC Thread	O-Ring Thread

Name	JIC Thread	O-Ring Thread
6402-O-4-4	7/16-20	7/16-20
6402-O-4-6	9/16-18	7/16-20
6402-O-6-6	9/16-18	9/16-18
6402-O-6-8	3/4-16	9/16-18
6402-O-8-6	9/16-18	3/4-16
6402-O-8-8	3/4-16	3/4-16
6402-O-10-10	7/8-14	7/8-14
6402-O-12-12	1-1/16-12	1-1/16-12
6402-O-14-14	1-3/16-12	1-3/16-12
6402-O-16-12	1-1/16-12	1-5/16-12
6402-O-16-16	1-5/16-12	1-5/16-12
6402-O-20-20	1-5/8-12	1-5/8-12
6402-O-24-24	1-7/8-12	1-7/8-12
