- Blade Type:V-Shaped
- Manufacturing Process:Brazing
- Application:Concrete, Stones, Construction Material
- Steel Blank:65 Mn
- Arbor Hole:25.4mm,22.23mm,20mm and as Required
- Segment Thickness:8mm,10mm,15mm,20mm and as Required
=== Base Info ===
- Model NO.:Laser welded
- Color:Red, Blue, Black and as Required
- Screen Printing:as Required
- Laser Engrave:as Required
- Transport Package:White Box, Color Box, Carton and Pallets
- Specification:From 100mm to 300mm are all available
- Trademark:PROTEC
- Origin:China
- HS Code:82023910
- Production Capacity:100000
=== Description ===
Basic Info.
Model NO.
Laser welded
Color
Red, Blue, Black and as Required
Screen Printing
as Required
Laser Engrave
as Required
Transport Package
White Box, Color Box, Carton and Pallets
Specification
From 100mm to 300mm are all available
Trademark
PROTEC
Origin
China
HS Code
82023910
Production Capacity
100000
Product Description
Basic infoModel No. | PT- PDVTPB | Application: | For cutting concrete, reinforced concrete, cured concrete and hard materials |
Samples: | Free samples when it is stock | Size: | 4"/105mm, 4.5"/115mm, 5"/125mm, 6"/150mm, 7"/180mm, 8"/200mm, 9"/230mm, 10"/250mm, 12"/300mm, 14"/350mm, 16"/400mm, 18"/450mm, 20"/500mm, 24"/600mm |
Arbor: | 25.4mm, 22.23mm, 20mm, 50mm and as required | Delivery Time: | Based on the Quantity |
Price Term: | EXW, FOB, CIF, CNF, DDP, DDU and Etc | Payment Term: | TT, LC, Western Union, PAYPAL, CREDIT CARD |
Color: | Green, Plain, Yellow, Blue and as required | Quality: | All have to pass 3 times QC inspection |
Certificate: | CE EN13236 | Test report: | Have |
Transport Package: | Double Corrugated Carton and pallet | Service: | Custom-made Service |
Sample order: | Available | Trademark: | Protec |
Origin: | China | HS CODE: | 82023910 |
Product SizeDiameter | Arbor hole | Use | Segment thickness | Segment height |
4"/105mm | 22.23mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
4.5"/115mm | 22.23mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
5"/125mm | 22.23mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
6"/150mm | 22.23mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
7"/180mm | 22.23mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
8"/200mm | 22.23mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
9"/230mm | 22.23mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
10"/250mm | 25.4mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
12"/300mm | 25.4mm, 20mm,50mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
14"/350mm | 25.4mm, 20mm,50mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
16"/400mm | 25.4mm, 20mm,50mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
18"/450mm | 25.4mm, 20mm,50mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
20"/500mm | 25.4mm, 20mm,50mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
24"/600mm | 25.4mm, 20mm,50mm and as required | Dry &Wet | 6.4/9.6/10/15/20mm and as required | 7/10/12/15mm |
Product Description: 1. Product: 125 x 10 x 6.4 x 22.23mm2. Usage: mortar removal, concrete3. Technology: Cold sintered/Laser/High frequency welded4. Body material: 65Mn5. Segment material: diamond grit, Cu powder, nickel powder, cobalt powder6. Diamond materials: higher diamond concentrationAdvantages:1) Smooth and fast cutting without chipping
2) Long lifespan and stable performance
3) Competitive price and superior quality4) Beautiful package and fast delivery5) Excellent serviceFeatures: 1. Application: for grooving hard granite, marble, engineered stone and ceramic tile
2. Wet cutting
3. Competitive price, quick, smooth cutting and long life
4.Arbor: 7/8'' -5/8'';Applied machine: Our V-Shaped Tuck Point Blades with thick kerf for grooving concrete & stones can be used on the Angle grinder, skill sawProduct show
Manufacturing process
Inspection
Cutting test
Why choose us
Company profile
Protec Tools Co.,Limited ,was established in 2006. As a professional and experiened diamond saw blade and drilling tools manufacturer , To give our customers best quality tools , make them work easier , more efficient and lower cost is what we always focused on . By continuous research, successful and unsuccessful experience, thousands of testing, PROTEC has developed best bonding for most of the building materials from different areas all over the world. In order to keep our products at a high level , we take the most advanced equipments in this industry,such as the automatic laser welding machine, automatic segment press and sintering machine etc.Our products are manufacted coordinate to CE/EN13236. All of these efforts leading a significant grows every year. All our customers will find it is happy to work with PROTEC for the satisfying products and service .Our products are exported to more than 30 countries all over the world and we are the OEM supplier of some world wide famous brands. Looking forward to work for you.
We export to more than 30 countries all over the world
Work shop
Fairs and customer meeting
CE CERTIFICATE
Our diamond saw blades are compliant to CE/EN13236 .
Our service
a) Good after-sale service, all questions will be replied within 12 hours.
b) Customized design is available. ODM&OEM are welcomed.
c) We can provide free sample.
d) Convenient transportation and fast delivery, all available shipping ways could be applied, by express, air or sea.
e) High quality and most competitive price.
f) Advanced produce and inspecting equipments.FAQ:
1. Can I order a small list?
---Yes. Of course you can.
2. What price do you offer?
---FOB, CIF, CNF, DDU, DDP and other ways according to your request.
3. How can we ship to you?
---By sea, By air, By express, By train and other transport ways according to your request.
4. What is the quality of your products guarantee?
---We have passed CE certification.
5.Do you have after-sales service?
---Certainly, you can contact us at any time.
