Premium 3W 5W 8W Ultraviolet (UV) UV Laser Marking Machine for Sale

• After-sales Service：Online Serive
• Laser Visibility：Visible
• Applicable Material：Nonmetal
• Cooling System：Air Cooling
• Technical Class：Continuous Wave Laser
• Laser Wavelength：Fiber Laser

=== Base Info ===

• Model NO.：3W 5W 8W
• Laser Classification：Free Electron Laser
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Transport Package：Standard Export Packing Plywood Package,Both Neutr
• Specification：450*210*415mm
• Trademark：NOBOT
• Origin：Liaocheng
• HS Code：8456110090
• Production Capacity：1000 Units,Month

=== Description ===

Basic Info.

Model NO. 3W 5W 8W Laser Classification Free Electron Laser Type Optical Fiber Laser Marking Machine Marking Method Scanning Marking Transport Package Standard Export Packing Plywood Package/Both Neutr Specification 450*210*415mm Trademark NOBOT Origin Liaocheng HS Code 8456110090 Production Capacity 1000 Units/Month

Product Description

uv laser marking machine

Product description
UV laser marking machine is a laser marking machine series of products. The machine is with 355nm UV laser controller, adopting
the third-order cavity frequency technology compared with infrared laser. The UV light spotlight is very small, easier to get a
great extent reduce the mechanical deformation of the material and the small impact of processing heat. Because the above
advantage, the UV laser was been mainly used for ultra-fine marking and sculpture area, especially for food, pharmaceutical
packaging materials marking, playing microporous, high-speed glass material and silicon Chip wafers for complex graphics cutting
applications.
Advantage
1.The good quality and small focus spotlight could achieve the ultra-fine marking with high speed and high efficiency.
2.The heat affected area is very small, no thermal effects, no material scorching problem.
3.The heat affected area is very small, will not produce thermal effects, will not produce material scorching problem.
4.Pre-installed high-precision practical multi-functional work surface, the table has a number of flexible screw holes, convenient
installation of special fixture platform.
5.In the design of the use of three-door closed processing, adpot high-quality special filter protection plexiglass production
dedicated observation window, to create the ultimate machine protection performance.
6.The cooling system is water cooling, to ensure that the laser long life, stability, reliable work and other characteristics.
Working environment requirement
1.Ambient temperature requirements at 18-35 ºC.
2.Humidity requirements <90%, no condensation, should be installed dehumidifier.
3.There should be no strong electromagnetic signal interference near the installation equipment. Install around to avoid the
infinite transmission station.
4.Ground amplitude: less than 50um; vibration acceleration: less than 0.05g. To avoid a large number of stamping and other machine
tools in the vicinity.
5.Equipment space requirements to ensure that smoke-free dust, to avoid metal polishing and other dust serious work environment.
6.Air pressure: 86-106kpa, Some environments should be equipped with anti-static floor to enhance the shielding.
7.Work cooling water quality of the circulating water is strictly required to require the use of purified water, deionized water
or distilled water, can not use tap water, mineral water and other high metal ions or other minerals.


Name	UV laser marking machine	Marking area	110*110mm/150*150mm/175*175mm /200*200mm/300*300mm
Power	3W/5W/8W	Minimum line width	0.01 mm
Laser wavelength	355 nm	Minimum character	0.1 mm
Laser type	UV Laser	Repetitive of positioning accuracy	0.003 mm
Laser source brand	INGU	Ambient temperature	15ºC-35ºC
Laser frequency	300-100 kHz	Ambient humidity	10%-85%RH, Non-Condensing
Laser power stability	about 5% rms	Power Supply	220V/50Hz
M2 beam quality	about 1.3	Power of machine	800W
Laser cooling	Water Cooling	Font Format	Support true type, JSF, SHX,DMF
Marking speed	0~6000 mm/s	Support file format	BMP,JPG,PNG,TIF,GIF,TGA,DXF,AI,AST,PLT
