PP Film Blowing Machine (MD-PP)

=== Base Info ===

=== Description ===

Basic Info.

Model NO. MD-PP Transport Package Nude Packing/Wooden Case Specification CE, ISO9001 Trademark Mingde Origin China HS Code 8477209000 Production Capacity 50sets/Year

Product Description

Product Description
PP film blowing machine
Material: Polypropylene or PP

Model	SJ-PP45
Suitable Material	PP
Film width	100-500mm
Film thickness	0.03-0.11mm
Max Extrusion output	30kg/hr
Screw diameter	φ 45
Screw L/D Length	28
1
Cylinder cooling	370W X 2
Driving Motor	11kw
Die size	φ 150

Air blower: 1.5kw
Pinch Roller (Dia. Width): φ 165X550
Take-up speed: 5-60m/min
Take-up motor: 0.75kw
Winding speed: 5-60 m/min
Winding motor(n. M): 5
Outline diameter (L*W*H): 3.2*2.0*3.5m
Voltage: 380V, 3phase, 50Hz

Model: SJ-PP55
Suitable Material: PP
Film width: 100-500mm
Film thickness: 0.03-0.11mm
Max Extrusion output: 45kg/hr
Screw diameter: φ 55
Screw L/D Length: 28: 1
Cylinder cooling: 370W X 2
Driving Motor: 15kw
Die size: φ 250

Air blower: 1.5kw
Pinch Roller (Dia. Width): φ 165X650
Take-up speed: 5-60m/min
Take-up motor: 0.75kw
Winding speed: 5-60 m/min
Winding motor(n. M): 5
Outline diameter (L*W*H): 4.2*2.5*34m
Voltage: 380V, 3phase, 50Hz

Model: SJ-PP65
Suitable Material: PP
Film width: 200-800mm
Film thickness: 0.03-0.11mm
Max Extrusion output: 60kg/hr
Screw diameter: φ 65
Screw L/D Length: 28: 1
Cylinder cooling: 370W X 3
Driving Motor: 18.5kw
Die size: φ 300

Air blower: 2.2kw
Pinch Roller (Dia. Width): φ 165X850
Take-up speed: 5-60m/min
Take-up motor: 0.75kw
Winding speed: 5-60 m/min
Winding motor(n. M): 6
Outline diameter (L*W*H): 4.6*2.8*4.5m
Voltage: 380V, 3phase, 50Hz
