500kg Meat/Sausage/Fish/Pepepr/Vegetable Hot Dry Smokehouse/ Smoke Oven

• Certification：CE, ISO9001
• Power Source：Electric
• Automatic Grade：Automatic
• Application：Meat,Sausage,Fish,Vegetable
• Customized：Customized
• Electricity：380,220V 50,60Hz, 3p

=== Base Info ===

• Model NO.：TUNE-500
• Output Capacity：500kg,H
• Transport Package：Standard Export Free Fumigation Box
• Specification：Customized
• Trademark：TUNE
• Origin：Shandong Province, China
• HS Code：8422303090
• Production Capacity：50 Sets Per Month

=== Description ===

Basic Info.

Model NO. TUNE-500 Output Capacity 500kg/H Transport Package Standard Export Free Fumigation Box Specification Customized Trademark TUNE Origin Shandong Province, China HS Code 8422303090 Production Capacity 50 Sets Per Month

Product Description

 Sausage Hot Fish Smoker Equipment Electric Smokehouse

 Introduction: 1. Smoke for sausage, ham, sausage, chicken, fish, duck and poultry, aquatic products and other smoked products. Cooking, drying, coloring by one time. 2. Smoked good color, taste better, quality assurance, excellent technology.

3. After smoking, the color of the food is good-looking, there is a smoked scent, not greasy feel, can achieve environmental effects, completely replace the traditional smoked furnace, save labor and improve work efficiency, but also enhances the taste of food and elastic. Automatic programmable control, simple and easy to operate.

4. Made of 304 stainless steel.

5. We have electrical type and PLC Computer touch screen type.





 Product Description

The product is given reasonable improvement, which has perfected the heating rate and fume smoking effect. The interlayer of the main machine frame is filled with imported high temperature resistant polyurethane frothing material which is able to guarantee good heat preservation,airtightness, energy saving and high efficiency. Specification of smoke house


	Model	TUNE-50	TUNE-100
	Outline Dimension	1220*1120*1750	1350×1200×1800
	Production Capacity	50Kg	100Kg
	Total Power	6kw	6kw
	High pressure steam pressure	3Mpa	0.3-0.6Mpa
	Low pressure stem pressure	1Mpa	0.1-0.2Mpa
	Max. High pressure furnace temperature	100ºC	100ºC
	Max. Low pressure furnace temperature	120ºC	85ºC
	Sausage cage truck	1 Set	1 Set
	Weight(Kg)	350	800

Model	TUNE-150	TUNE-200
Outline Dimension	1390×1230×2450	1390×1230×2600
Production Capacity	150kg	150kg
Total Power	8.5kw	8.5kw
High pressure steam pressure	3 Mpa	3 Mpa
Low pressure stem pressure	1 Mpa	1 Mpa
Max. High pressure furnace temperature	100ºC	100ºC
Max. Low pressure furnace temperature	85ºC	85ºC
Sausage cage truck	1 Set	1 Set
Weight(Kg)	800	1000
