Hydraulic Multi-Directional Flow Control Valve Zycdb-F15L

• Function：Flow Control
• Installation：Superposition
• Drive：Hydraulic
• Type：Directly Operated Type
• Nominal Pressure：200 Bar
• Nominal Size：20 mm

=== Base Info ===

• Model NO.：ZYCDB-F15L-T,AZ
• Nominal Flow Rate：180 L,Min
• Number of Blocks：1 to 8
• Dividing Flow：23-31 L,Min
• Pressure of Dividing Valve：120 Bar
• Spool Stroke：8+8mm
• Weight：10.4+5.6n Kg
• Customized Service：Ok
• Application：Forklift, Crane, Construction Machinery
• Transport Package：Packed in Exported Standard
• Specification：as drawing
• Trademark：Heye & HCHC
• Origin：Anhui, China
• Production Capacity：6000 PCS,Month

=== Description ===

Basic Info.

Model NO. ZYCDB-F15L-T/AZ Nominal Flow Rate 180 L/Min Number of Blocks 1 to 8 Dividing Flow 23-31 L/Min Pressure of Dividing Valve 120 Bar Spool Stroke 8+8mm Weight 10.4+5.6n Kg Customized Service Ok Application Forklift, Crane, Construction Machinery Transport Package Packed in Exported Standard Specification as drawing Trademark Heye & HCHC Origin Anhui, China Production Capacity 6000 PCS/Month

Product Description

Performance Characteristics:

★ compact structure
★ strong flow capacity
★ low pressure loss
★ reliable work
★ high security

ZYCDB-F15L-T/AZ multi-way valve is mainly applied in load sensing forklift under 3.5T. The valve is of plate structure with integrated priority steering function.




Nominal pressure (bar)	200
Nominal size (mm)	15
Nominal flow  (L/min)	65
Valve shaft stroke (mm)	7+7
