advertisement Sign Acrylic Cutting 130W CO2 Laser Engraving and Cutting Machine

• Application：Leather Industry, Domestic, Carpentry, Printing & Packaging, Construction Industry, Molds & Dies, Crafts Industr, Advertising Industry, Clothing Industry
• Cooling System：Water Cooling
• Technical Class：CO2 Laser
• Automatic Grade：Automatic
• Applicable Material：Nonmetal
• Type：CO2 Laser

=== Base Info ===

• Model NO.：RJ1325P
• Laser Classification：CO2 Laser
• Engraving Method：CO2 Laser Scan Engraving
• Working Size：1300*2500mm
• Power of Laser Tube：60W,80W,100W,130W,150W,180W,200W,260W,300W
• Control System：Ruida
• Laser Tube Brand：Beijing Reci
• Guide：Hiwin
• Weight：1200kg
• After Sale Service：Video Support and Online Service
• Voltage：AC220V 50Hz,60Hz
• Warranty：1 Year
• Transport Package：Plywood Case
• Specification：3.3* 2.26*1.3m
• Trademark：RuiJie
• Origin：Jinan City, Shandong, China
• HS Code：8456100090
• Production Capacity：1000sets,Year

=== Description ===
Advertisment Sign Acrylic cutting 130w CO2 laser Engraving and Cutting machineModelRJ-1325Working Size1300X2500mmLaser TypeCO2 Sealed Laser Tube,wavelength 10.6μm (In accodance with GB11748-89 standard)(Optional frequence metal tube)Laser Power 60W,80w,100W, 130W, 150W, 180W, 200W, 260WEngraving Speed0-1200mm/sCutting Speed0-600mm/s (the speed is varied due different thickess of materials)Energy Adjusment0-100% stepless control, inside software 0-100% adjustControl SystemDigital Offline Control SystemCutting Thickness0.2-16mmWhole Machine Power≤3000WPosition Accuracy<±0.05mmMinimum Letter SizeChinese:1.5mm  English:1mmCooling SystemIndustrial Water Cooling SystemDriving SystemStepper motor and driversWorking VoltageAC220V/110V±10% 50Hz/60HzWorking EnvironmentTemperature:0-45ºC,humidity:5%-95% non-condensateSupported FormatPLT,DST,DXF,BMP,AI, support AutoCAD,CorelDraw output directly.

FEATURES

- Dark-brown window keep operator's eyes safe.

- Aluminum alloy knife strip working table, ensure high quality cutting.

- Motorized up down working table enable thick material engraving and cutting.

- Closed cover design for good effect smoke exhausting and dust proof.

- Separate control box -electric parts protection, anti-interference and extended service life.

- 1:2 Wheel speed ratio to keep high quality cutting effect.

-RD screen control system in English--operate easily

-Leedshine driving system--stable

-HIWIN guide rail from Taiwan -- high precision

-Singapore lens and mirror--reflection and focusing, long working life.

-Red light position system --position precision

-Automatic protection system--safe


Application:

(1). Applicable materials:

Acrylic, wood, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic,glass and other nonmetal materials,etc.

(2). Applicable industries:

 1,Advertising industry: Double-colored board carving,  Organic glass carving and cutting,label carving, crystal cup carving, Warranty signed carving.

 2,Carved gifts and crafts industry: Wood, Bamboo, Ivory, Bone, Leather,  paper.

 3,Packing and printing industry:  Rubbery board,  Plastic board, Double-layered board   ,Model cutting board.

 4,Leather clothing industry: Complex characters and pattern carving ,Cutting on hypoderm,     Synthetic leather ,Man-made leather ,Cloth .

 5, Architectural model industry: ABS board cutting ,Model carving.

 6,Production totem industry:  Appliance signs, Anti-fake commodities marking.



PACKAGING

Packaging:CO2 Cutting Machine will be packed by two layers. First the plastic air bubble wrap the machine, protect the Laser Cutting Machine from be scratched or other unexpected damage, the wrapped product will be packed in plywood case.

Shipping: Shenzhen, Shanghai, Qingdao, Guangzhou,etc. We accept land, air, sea transport and international multimodal transport.  land, air, sea transport and international multimodal transport.


SERVICE

*12 months quality guaranty, the machine with main parts(excluding the consumables)shall be changed free of charge if there is any problem during the warranty period.

*Lifetime maintenance free of charge.
*Free training course at our plant.
*We will provide the consumable parts at an agency price when you need replacement.

*24 hours on line service each day, free technical support.
*Machine has been adjusted before delivery.
*Our staff can be sent to your company to install or adjust if necessary.
