Basic Info.

Model NO. SJ Machine Weight 1.5t Certification CE, ISO9001:2008 Film Thickness(mm) 0.008*0.1 Voltage Support 380V/50Hz Winding Speed 5-50m/Min Motor AC Motor Extrusion Capacity(Kg/H) 35kg Screw L/D Ratio 30:1 Screw 50mm Transport Package as Require Specification CE. SGS Trademark YunBang Origin China HS Code 8477309000 Production Capacity 20 Sets/Month

Product Description

HDPE&LDPE blow machine extrusion die head /
pe film blowing machine polypropylene machine

use:
Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitrized and processed in a precision way.
Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity. It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene(HDPE) and linear low density polytene (LLDPE). It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.

Main Technical Varia:


Model	A50	A55	A65	A65-1
Diameter of screw	φ 50	φ 55	φ 65	φ 65
Rcduced diameter of film(mm)	100-600	200-800	300-1000	400-1200
Single-face Thickness of film(mm)	0.01-0.10	0.01-0.10	0.01-0.10	0.01-0.10
Max. Extrusion (Kg/h)	35	50	65	80
L/D	28: 1	28: 1	28: 1	28: 1
Power of main moto (kw)	7.5-11	11-15	18.5-22	22
Power of Tracion main moto (kw)	1.1	1.1	1.5	1.5
Heating Power (kw)	11	13	19	21
Outline diameter(L x W x H) (mm)	4800 x 1900 x 3500	5500 x 2100 x 3800	6500 x 2300 x 4200	6500 x 2500 x 4800

Overview:




Packing&Shipping:



Advantages:
1. We're factory suppliers of film blowing machine, printing machine, bag making machine and recycling machine, and laminating machine.
2. Not only a good quality and competitive price are promised, each of our customer can also enjoy oversea service  and one-year quality guranantee under normal operation!!!
3. Machine videos are clear and waiting for you to check. If you need a factory tour, wanna get a closer look to finished products, go and contct us right now!!! We sincerely welcome you to visit our factory.






Welcome to contact  us for further details and price!!
